0510425009 AZPF-1X-008RCB20MB German Rexroth gear oil pump
Price:
Negotiable
MOQ:
1
Delivery Time:
2 weeks
Brand:
Rexroth
Product Description
0510425009 AZPF-1X-008RCB20MB German Rexroth Gear Oil Pump
High-performance external gear pump designed for demanding industrial appliions with robust construction and reliable operation.
Technical Specifiions
| Manufacturer Part No. | 0510425009 |
|---|---|
| Pump Type | External Gear Pump, Fixed Displacement |
| Series / Platform | AZPF Series F (High Pressure) |
| Geometric Displacement | 8.0 cm³/rev |
| Rotation (viewed from shaft end) | Clockwise (Right-Hand) |
| Pressure Ratings | Max. Continuous: 250 bar Max. Intermittent: 280 bar Peak Pressure: 300 bar |
| Speed Range | Recommended: 1000 - 3000 rpm Maximum: 3500 rpm (dependent on suction conditions) |
| Drive Shaft | Tapered 1:5 with Key (Ø18 mm) |
| Port Connection | Square Flange (ISO 8434-1) |
| Mounting Flange | Rectangular Flange, Ø80 mm |
| Housing Material | Aluminum |
| Sealing Material | NBR (Standard) |
| Weight | Approx. 3.4 kg |
| Hydraulic Fluid | Mineral-based oils (HL, HLP), HFC, HFD, HETG, HEPG, HEES |
| Viscosity Range | 12 - 800 mm²/s (Optimal: 20 - 100 mm²/s) |
| Fluid Cleanliness | NAS 1638 Class 10 (Recommended: Class 9) |
Product Image
Related Models
Frequently Asked Questions
Product & Selection
What does the model code "AZPF-1X-008RCB20MB" mean?
It decodes as follows:
- AZPF: Series code for high-pressure external gear pumps
- 1X: Frame size / bearing specifiion
- 008: Nominal displacement (8.0 cm³/rev)
- R: Clockwise rotation
- C: Tapered shaft 1:5
- B20: Port and flange configuration (Square flange per ISO 8434-1)
- MB: Variant code for seals and covers
Is this pump suitable for high-pressure appliions?
Yes. The AZPF series is designed for heavy-duty use. This model can handle continuous pressures up to 250 bar and intermittent peaks up to 280 bar, making it ideal for industrial machinery and mobile hydraulics.
Can I get this pump in counter-clockwise rotation?
Yes. Rexroth typically offers a left-hand rotation version (denoted by an 'L' in the suffix, e.g., `...LCB...`). Always verify the rotation direction before installation.
Installation & Operation
What is the recommended operating viscosity?
Operate within 12 to 800 mm²/s. For optimal efficiency and service life, maintain viscosity between 20 and 100 mm²/s. Avoid prolonged operation below 12 mm²/s to prevent internal wear.
What is the maximum allowable speed?
The absolute maximum speed is 3500 rpm. However, the recommended continuous operating range is 1000 to 3000 rpm. Exceeding 3000 rpm may require special suction conditions (e.g., pressurized inlet) to avoid cavitation.
How do I calculate the flow output?
Use the formula:
Flow (L/min) = Displacement (8.0 cm³/rev) × Speed (rpm) / 1000
Actual flow will be slightly less due to volumetric losses (typically 90-95% efficiency).
Flow (L/min) = Displacement (8.0 cm³/rev) × Speed (rpm) / 1000
Actual flow will be slightly less due to volumetric losses (typically 90-95% efficiency).
Maintenance & Troubleshooting
What are common failure signs?
Watch for:
- Noise: High-pitched whining indies cavitation (check inlet suction); knocking suggests bearing wear
- Reduced Flow: Often caused by worn gears or side plates due to contamination
- External Leakage: Usually from the shaft seal (NBR), often due to age or excessive shaft play
Can this pump be repaired in the field?
While Rexroth provides seal kits, the AZPF pump uses precision sliding bearings and pressure-compensated side plates. Replacing seals is possible, but rebuilding the internal gear set requires specialized tools and pressure testing. For critical appliions, an exchange unit is often recommended.
What is the #1 cause of premature failure?
Oil contamination. This pump requires very clean oil (NAS Class 9-10). Always use a pressure filter with a beta ratio (β10) ≥ 100. Running with a clogged suction filter or low oil level can cause cavitation and astrophic damage.
Disclaimer: This data is based on standard Rexroth documentation for the AZPF series. Always refer to the official RE 10 250 datasheet for your specific appliion and safety guidelines.
