Ball Lock Mounting System Manual High Precision Ball Lock Shaft
-
Material: 4340 Steel
-
Finish: Black Oxide
-
Heat Treat: Shanks: 40-45 RC
-
Operating Temperature Range: -20°F to 400°F (-30°C to 200°C)
Repetitive positioning accuracy<± 0.013mm;
The Ball Lock Mounting System is a manual, high-precision solution for rapid and repeatable component positioning. This system utilizes a precision-machined shaft with locking balls that engage with a corresponding mount, ensuring rigid and accurate location every time. Ideal for fixture plates, molds, and automated applications, it allows for tool-less changes in seconds, drastically reducing downtime. The manual operation provides a simple, reliable mechanism for achieving micron-level repeatability without complex hydraulics or pneumatics. Enhance your production efficiency with this robust ball lock shaft, designed for seamless integration and unparalleled accuracy in demanding industrial environments.
| PART NUMBER | CLAMPING FORCE(KN) | TIGHTENINGI TOROUE (KN) | TIGHTENINGI ADAPTER PLATE (Nm) (±0.13) | ΦD1 | ΦD2 | H | H1 | M | SW |
WEIGHT (kg) |
| QSP-16020 | 5.3 | 4.5 | 20 | 32 | 16 | 36.5 | 8 | M6 | 3 | 100 |
| QSP-16025 | 5.3 | 4.5 | 25 | 32 | 16 | 41.5 | 8 | M6 | 3 | 110 |
| QSP-20020 | 13.3 | 5.3 | 20 | 40 | 20 | 39.5 | 10 | M6 | 3 | 200 |
| QSP-20025 | 13.3 | 5.3 | 25 | 40 | 20 | 44.5 | 10 | M6 | 3 | 230 |
| QSP-25020 | 30 | 11 | 20 | 45 | 25 | 44 | 10 | M8 | 4 | 270 |
| QSP-25025 | 30 | 11 | 25 | 45 | 25 | 49 | 10 | M8 | 4 | 300 |
| QSP-30020 | 44 | 18 | 20 | 50 | 30 | 49 | 13 | M10 | 5 | 360 |
| QSP-20025 | 44 | 18 | 25 | 50 | 30 | 54 | 13 | M10 | 5 | 400 |
