Screw Locator Locating Pin Fixture CNC Components Manual Quick Change Clamp

Product Features:

1. Simple Manual Setup
2. High-Precision Location.
3. Locating Repeatability 3µ.
4. Min. Tightening Force 1200-3000 N.
5. Max. Loading Weight - Horizontal Mounting: 100-800kg, Vertical Mounting: 20-160kg

Screw Locator with a movable taper sleeve performs high-precision locating of pallets and

plates simply by fastening the bolts, Cut Pin, Tightening Bolt Size M12, Option PC.

This manual quick-change clamp system, featuring a robust screw locator and precision locating pin, redefines efficiency in CNC fixture setup. The integrated components work in unison to provide rapid, tool-less changes and micron-level repeatable positioning. The screw locator securely clamps the workpiece, while the hardened locating pin ensures perfect alignment, eliminating errors. Ideal for modular fixtures and high-mix production, this solution drastically reduces non-cutting time between jobs. Achieve unparalleled accuracy, enhance workflow flexibility, and maximize machine uptime with this essential, high-performance workholding combination for demanding manufacturing environments.
