Product Introduction
The RD-3605 is a small, lightweight, compact, portable industrial X-ray flaw detector with strong penetration, saving time and effort, high stability, low failure rate, and continuous 15-minute exposure operation without 1:1 rest. It is suitable for X-ray non-destructive testing in power plant installations, shipbuilding, chemical pipelines, chemical containers, natural gas and oil pipelines, chemical spherical tanks, and large-diameter pipelines (double-wall single-image radiography). It improves work efficiency by 50%. The equipment is lightweight and portable, with the generator weighing only 34kg, and features a compact design. This series of equipment is available in directional and circumferential versions, with a maximum penetration thickness of 55mm for Q235 steel.
RD-3605 Technical Specifications
| Item | RD-3605 | |
| Input | Input Power Supply | Single-phase 50Hz AC 220±10% V |
| Power Supply Capacity | Not less than 3.0 KVA | |
| Output | X-ray Tube Voltage | 200~ 360 KVp |
| X-ray Tube Current (mA) | 5mA | |
| Stability | ± 1% | |
| Radiator | Focus Size | 3.0× 3.0 |
| Radiation Angle | 40±5° | |
| Radiation generator | Working pressure; Cooling method; Insulation method |
0.45MPa ~ 0.5MPa Anode grounded radiator with forced air cooling Gas insulated SF6 |
|
Dimensions Weight (kg) |
Φ320×320×640 | |
| 34 | ||
| Maximum Penetration | Thickness steel A3 (mm) | 55(5min) |
| Conditions | Focal length 600mm, Agfa film, double-sided lead foil sensitizer, chemical temperature 22 degrees Celsius, film density ≥2.0. | |
| Sensitivity | Better than 2% | |
| Controller |
Dimensions Weight Circuit |
325×270×180 < 9(kg) Automatic control and protection |
| Environment |
Operating temperature Relative humidity Altitude |
-30°C to +40°C; not exceeding 85%; not exceeding 1500 meters. |
| Method | Fully automatic 2.5:1 work/rest cycle, longest continuous exposure time is 15 minutes. | |
