Fluorescent UV Aging Test Cabinet
Price:
CN¥1,428.58/boxes >=1 boxes
MOQ:
One set
Delivery Time:
Negotiable
Brand:
Daxian
Product Description
Main technical parameters:
box structure -Warehouse board (insulation layer thickness 100mm~150mm)
Sample temperature range -55~85 ℃ (supports non-standard customization)
temperature uniformity - ±2℃
Sample temperature uniformity - ±4℃
light source driver -EPS
Light source category - Metal halide lamp
light source power - 2kv
Lamp quality assurance -1500h
spectral range -280-320nm 320-400nm
service life - ≥2500h
UVB/(UVA+UVB) -3%~10%
Light intensity range - ≤ 250W/m ² (can be upgraded to a maximum of 900Wm?)
non-uniformity - ≤±10%
Customized functions
cooling method -- air cooling
Test purpose:
Before carrying out thermal cycling and wet freezing accelerated aging tests, all photovoltaic module samples undergo pre-exposure under controlled ultraviolet radiation. The core aim of this preconditioning step is to assess the anti-ultraviolet performance of polymeric materials and sealant adhesives that tend to degrade, discolor or delaminate when exposed to UV light over extended periods.
customized service
-XY axis uniformity scanning system - multiple UV testing
-UV+DH testing
-UV+HF testing
Meet the standards:
IEC61215-2MQT10
IEC61730-2 MST54
