Portable Mini 20W 30W 50W Handheld Laser Marking Machines Laser Engraving Machines
20w 30w 50w Mini Portable Handheld Laser Engraving Marking Machine Small Desktop Metal Sheet Plate Laser Marker Engraver Etching Machine
Feature:
-
Lightweight and flexible: light weight, compact size, easy to carry
-
Plug and play: it can be used after power on, no complicated installation and debugging required
-
Handheld operation: the marking head can be held in the hand and directly marked on the surface of the target object
-
No consumables, low cost: the laser equipment has a long service life and does not require ink or labels
-
High precision and clear marking: the laser line width can reach 0.01mm, and the permanent mark is not easy to wear
-
Widely compatible materials: suitable for metal, stainless steel, aluminum, ABS, PVC, leather, etc.
-
Support graphic QR code: can print QR code, barcode, LOGO, production batch number, serial number, etc.
Specification:
| Laser Wavelength | 1064nm |
| Output Power | 20W/30W/50W(can be chosen) |
| Repetitive Frequency | 10-200KHz |
| Marking Range | 110*110mm/140*140mm/175*175mm(can be chosen) |
| Minimum line width | 0.03mm |
| Carving depth | <0.2mm(depend on material) |
| Minimum character | 0.15mm |
| Carving line speed | <20000mm/s |
| Repetitive accuravy | ±0.003mm |
| Cooling Mode | air cooling |
| Application | Applicable to various metal materials (stainless steel, iron, copper, aluminum, magnesium, zinc, rare metals, alloys, etc.), some non-metallic materials (engineering plastics, electroplating materials, spraying materials, inks, ABS, plastic rubber, epoxy resin, etc.) |
Fast Questions and Answers.
Q: What can you buy from us?
A: Laser Cleaning Machine, Laser Welding Machine, Laser engraving machine, Laser Cutting Machine, Laser machine accessories like laser head, laser lens etc.
Q: I don’t know which one is suitable for me ?
A: You can let us know what materials you are working with, and what you want to do with them, we will offer advise or recommend suitable machine to you.
Q: How to operate the machine?
A: We will send you English manual and guide video, usually the machines are very easy to operate. If you still need our further help, please contact us, we have technicians to help.
Q: How long is your warranty?
A: Our warrant for whole machine is 1 year without man-made quality problems, while for laser source our warranty is 2 years. If you have any problems beyond warranty we will offer online technical helps and low cost spare parts replacement.
Why choose us?
1. 10+ years experiences in laser machine field. Our co-founder is growing together with Chinese laser machine industry and we have rich resources for all kinds of laser machines. Now we work with our domestic brand factory in Shenzhen, both quality and advanced technology can be guaranteed for you.
2. Our technicians dedicate to make our final machine to be stable and easy-operated, so most people can use them easily as long as you follow our manual instructions. Besides, we also support with on-line/video guide. For special projects we provide oversea spot technique supporting.
