Pulse Mini Laser Welding Machine Jewelry Laser Welder Equipment 1000w
Auto CCD Camera Laser Metal Welding Machine Muti station disc laser welding machine for Metal
The Rotary Indexing Table Laser Welding Machine is a laser welding machine that integrates automation, multi-station and high efficiency. It is widely used in the welding of batches and small precision parts. The equipment uses a servo-driven indexing table (rotary table/turntable structure), combined with a laser welding head and a fixture, so that welding, loading and unloading, and testing processes can be carried out simultaneously at multiple stations, significantly improving the welding cycle and production capacity.
What's The Advantages Of Our Machine?
-
Multi-station parallel: welding, loading and unloading, and testing can be carried out at the same time, saving time and improving production capacity.
-
High efficiency: the welding of a product can be completed in one cycle, and the beat can reach 3~8 seconds/piece.
-
Strong consistency: the workpiece positioning is fixed, the welding path is stable, and the weld consistency is good.
-
High degree of automation: support system integration such as manipulator, vibration plate, and visual guidance.
-
Save labor costs: almost fully automatic operation is achieved, and only one person is required to load or supervise.
-
Suitable for mass production: especially suitable for scenes with standardized product structure and large amount of repeated processing.
-
Strong scalability: the number of stations, welding methods, and control logic can be customized.
Specification:
| Laser Type | Fiber(Continuous/Pulse) |
| Laser Wavelength | 1070nm±5nm |
| Laser Power | Continuous: 1000-6000W Pulse: 100/1000-400/4500W |
| optical fiber core radius | 14/20/50/100μm |
| Platform motion range | 500*300mm |
| Rotary diameter | 900mm |
| Rotary positioning accuracy | ±15 arcsec |
| Laser Modes | Continuous/Pulse |
| Laser Indicator | Red light+HD CCD |
| Cooling Mode | air cooling/water cooling |
Why Choose us?
1. 10+ years experiences in laser machine field. Our co-founder is growing together with Chinese laser machine industry and we have rich resources for all kinds of laser machines. Now we work with our domestic brand factory in Shenzhen, both quality and advanced technology can be guaranteed for you.
2. Our technicians dedicate to make our final machine to be stable and easy-operated, so most people can use them easily as long as you follow our manual instructions. Besides, we also support with on-line/video guide. For special projects we provide oversea spot technique supporting.
Rotary Indexing Table Laser Welding Machine
