1100T High Speed Hydraulic Aluminum Extrusion Machine Popular Aluminum Press
Price:
$159400-$182000
MOQ:
1 Pcs
Delivery Time:
3 Months
Brand:
Huanan
Product Description
1100T High Speed Hydraulic Aluminum Extrusion Machine Popular Aluminum Press
Product Specifications
| Attribute | Value |
|---|---|
| Material | Steel Forging |
| Uses | Extrusion |
| Color | Customized |
| Craft | Forging |
| Power | Electric energy |
| Size | Customizable |
| Use | Aluminum Extrusion |
| Motor | Servo or ordinary motor |
| Functional | Automatic or semi-automatic |
| Surface treatment | Heat treatment |
Product Overview
The 1100T aluminum extrusion press is a highly productive and versatile machine, offering an optimal balance between power, speed, and cost-efficiency. Designed for industries requiring medium-to-large aluminum profiles with high precision and fast cycle times.
Technical Specifications
| 1000MT/1100UST Technical Parameters | |
| Standard Billet Size: | |
| Outer diameter: | Φ127mm |
| Length: | 400-680/750mm |
| Extrusion capacity: | |
| Machine extrusion force: | 21Mpa 1000T(1100UST) |
| Dimensions of mold base cavity: | |
| Diameter: | Φ250mm |
| Depth: | H260mm |
| Equipment dimension: | |
| Mechanical size: | L9500mm*W3200mm*H3900mm |
| Overall weight: | 55T |
| Total Power: | 182.5KW |
| Motor: | |
| Main oil pump (Hilectro brand): | HP12981-G102W-R1P4 |
| Liquid cooling driver: | Hi300-90KW |
| Hydraulic pump: | |
| Main oil pump (Germany Rexroth): | A15VSO210 variable pumps |
| Auxiliary pump (Tokyo Keiki): | SQP43-60-38 |
Advantages of Short-Stroke Back Loading Structure
- The extrusion stroke is notably shorter than conventional extruders, resulting in a reduced frame opening. This design increases stress frame rigidity by 30% compared to traditional extruders.
- Decreased main side cylinder volume minimizes hydraulic oil usage, enhancing speed and pressure control accuracy while shortening pressure adjustment time. This reduces energy consumption and mitigates oil impact during pressure relief.
- Elimination of gasket circulation system reduces reactive operation time and power consumption, decreasing non-extrusion time by 15%.
- Translation manipulator powered by servo motor contributes to 15% reduction in non-extrusion time.
Application Fields
Our hydraulic aluminum extrusion machine serves diverse industries including:
- Construction Industry
- Industrial Trade
- New Energy Industry
- Photovoltaic Industry
Aluminum profiles produced by this machine are used for roofing, walling, doors and windows, framing, reticulated shell structures, glass curtain walls, awnings, pedestrian bridges, interior/exterior decorative panels, partitions, ceilings, railings, and handrails. They also serve as structural components in storage containers and formwork.
Technical Characteristics
- Key components (container, extrusion pad, shear blade, ingot feeder) feature mature structures with low failure rates
- Minimal impact and vibration with reduced oil leakage potential
- Fast response time with high efficiency and short non-extrusion periods
- High precision with extrusion speed control accuracy of ±0.1mm
- Advanced automation and intelligent production reduces operator requirements
Product Images
Frequently Asked Questions
Q1: How is the quality of Huanan Brand machine and the service life?
Huanan Brand is among China's top extrusion equipment manufacturers. Customer feedback indicates a typical machine lifespan exceeding 15 years with proper maintenance. Many well-known aluminum manufacturers are our satisfied customers.
Q2: How to choose the right type machine?
Please provide details about your products and profile sectional drawing dimensions. Our engineers will calculate the optimal machine size for your requirements.
Q3: Will Huanan provide installation service?
When the machine arrives at your facility and installation conditions are met, we dispatch technicians for installation and operator training.
Q4: What is the delivery time of Huanan Machines?
- 600-1000MT machines: 30 days
- 1250-1800MT machines: 45-60 days
- 2000-3000MT machines: 180 days
- 3000MT+ machines: 6-12 months
Q5: What services does Huanan provide?
Huanan offers comprehensive one-station services including:
- Technical consultation and support
- Custom production proposals
- Design, manufacturing, inspection, shipping with full documentation
- Installation, training, and lifetime maintenance support
