160NC/P CNC Carbide Circular Sawing Machine for Metal Alloy Industrial Cutting
JSSCD-160NC is our self-developed high-speed intelligent horizontal push CNC carbide circular saw machine. Built with rigid HT250 cast iron bed and premium global brand core parts, it delivers stable, low-vibration cutting with high precision and smooth burr-free sections. Fully CNC automatic operation covers auto feeding, clamping, cooling and chip removal. It cuts various steels, aluminum, copper, titanium alloys and PA plastic, widely serving automotive, aerospace, mold, hardware and pipeline manufacturing industries for mass bar cutting.
Adopting horizontal push servo feeding and an exclusive saw blade stabilization system, this circular saw effectively reduces vibration to extend saw blade service life. It comes with integrated automatic lubrication, spray cooling and chip removal devices, plus an optional oil mist purifier for eco-friendly workshop operation. Equipped with PLC touchscreen control and reserved production line interfaces, it easily connects to automated workshops to boost cutting efficiency and lower labor costs for long-term industrial mass production.
- Sturdy HT250 cast iron machine base with aging treatment, ultra-rigid & deformation-resistant
- Horizontal push servo feeding + proprietary saw blade stabilization system, low vibration & long saw blade life
- Full CNC automatic workflow: auto loading, clamping, cooling, chip & scrap separation
- Global premium core components (SKF/NSK bearings, XINJE PLC) for stable low-failure operation
- Eco-friendly spray lubrication cooling; optional 95% high-efficiency oil mist purifier
- Reserved Ethernet interface, compatible with automated production line integration
- Multi-protection alarms for lubrication, hydraulic pressure and air shortage for safe operation
| Model | Unit | JSSCD-160NC/P |
|---|---|---|
| Mainframe dimension(L*W*H) | mm | 2376*2271*1970 |
| Bar&round pipe | mm | 40-160 |
| Angle bar□ tube | mm | 40-125 |
| Spindle motor power | KW | 18.5/6P |
| Spindle speed | rpm | 30-120 |
| Feed servo motor power | KW | 3 |
| Feeding servo motor power | KW | 3 |
| Material removal length at the front end | mm | ≥10 |
| Single feeding length(repeatable feeding) | mm | 10-750 |
| Hydraulic drive motor power | KW | 3.75(4P) |
| Saw blade size | mm | Φ485x2.25x2.7xΦ50 |
| Pin holes and hole diameters | mm | 4xΦ16x80Φ50 |
| Hydraulic oil capacity | L | 168 |
- Automatic saw blade chip cleaning brush to avoid secondary cutting
- Material separating device auto sorts finished workpieces, heads and tails
- Built-in workpiece counting function with auto-stop at set quantity
- Multi-condition safety alarms for oil level, hydraulic pressure and air supply
- Independent enclosed automatic lubrication system with timing lubrication
- Standard chain-plate chip conveyor for easy metal scrap collection
- Reserved Ethernet communication port for smart production line docking
- Optional two-stage oil mist collector with over 95% purification efficiency
![]()
![]()
![]()
Q1: Does the band saw blade have any international certifications?
A: Yes, we have obtained CE, ISO international certification.
Q2: What is your method of transaction?
A: We adopt the FOB(Free ON Board) transaction.
Q3: Are you a manufacturer or a trading company?
A: We are a professional manufacturer of saw blade grinders. We have a 30,000 square meter factory and a team of dedicated technicians specializing in design, manufacturing, and sales.
Q4. How does the machine guarantee cutting precision and extend saw blade life?
A: It adopts horizontal push servo feeding and proprietary saw blade stabilization system to reduce vibration. Built-in wire brush cleans saw teeth to avoid secondary cutting.
Q5: What supporting accessories are included in the standard supply scope?
A: Standard package contains 1 main machine, 6-meter feeding rack, one φ480 saw blade, complete tool set and installation spare parts like expansion screws.
