ICU Surgical Hospital Pendant Systems With Dry Wet Separated Pneumatic
Price:
3500USD-3750USD
MOQ:
1
Delivery Time:
2-4weeks
Brand:
JYK
Product Description
ICU Surgical Hospital Pendant Systems With Dry Wet Separated Pneumatic
Pneumatic Hospital Surgical ICU Rail Pendant System with dry-wet separated pneumatic design for operation rooms and ICU applications. Features medical pendant systems with both dry and wet combined configurations for intensive care units and surgical environments.
Dry Part Specifications
- Power supply: AC220V, 50Hz, input power: 6kVA
- Bridge length: 2800-3000mm (according to room size requirements)
- Moving range: 0-400mm
- Instrument shelves: 3PCS (height adjustable), fillet design to avoid collision
- Exclusive ultrathin design to save space with high strengthen aluminum material
- Gas outlets: O2: 1PCS, vacuum: 1PC, compressed air: 1PC
- Different color and shape to avoid wrong attachment
- Service life: 20,000 cycles
- Second sealing, three states: Connecting, close, pullout
- Can be repaired while connected with gas source
- Power sockets: 6PCS, 220V, 10A
- Ground terminals: 2PCS
- RJ45: 1PC, LED light: 1PC
- Stainless steel drip hanger: 1PC
- Stainless steel infusion pump shelf: 1PC
- Storage basket: 1PC, drawer: 1PC
- Brake system: compressed air
- Weight capacity: 80-150kg
- Horizontal rotation: 0-340°
Wet Part Specifications
- Moving range: 0-400mm
- Rotary arm length: 450mm, horizontal rotation: 0-340°
- Instrument shelves: 2PCS (height adjustable), fillet design to avoid collision
- Exclusive ultrathin design with high strengthen aluminum material
- Gas outlets: O2: 1PC, vacuum: 1PC, compressed air: 1PC
- Different color and shape to avoid wrong attachment
- Service life: 20,000 cycles
- Second sealing, three states: Connecting, close, pullout
- Can be repaired while connected with gas source
- Power sockets: 6PCS, 220V, 10A
- Grounding terminals: 2PCS
- Stainless steel drip hanger: 1PC
- Stainless steel infusion pump shelf: 1PC
- Storage basket: 1PC, drawer: 1PC
- Horizontal rotation: 0-340°
- Brake system: compressed air
- Load weight: 60-100kg
System Construction & Options
- Material: High strengthen aluminum alloy
- Electrostatic coating
- Ceiling mounted, stable and firm construction
- Total system weight: 330kg
- Optional components: Instrument shelves, gas outlets, VGA connector, telephone connector, intercom connector, power sockets, grounding terminal, drip hanger, infusion pump shelf
| Feature | Specification |
|---|---|
| Pendant Quantity | 2 pcs (one for dry, one for wet) |
| Gas Outlets | O2: 4PCS, Vacuum: 4PCS, Compressed Air: 2PCS |
| Service Life | 20,000 cycles |
| Brake System | Pneumatic |
| Ground Terminals | 4PCS |
