4MP 33X Anti-Corrosion IR PTZ Starlight WDR IP Marine CCTV Camera with wiper
| Material | Stainless Steel 316L |
|---|---|
| Resolution | 4MP |
| Focal Length | 4.5-148.5mm, 33X optical zoom |
| Power | AC30V/POE++/AC110V-240V/DC24V-36V etc optional, ≤85W |
| IR Range | 150m (300m is optional) |
| Dimensions (L*W*H) | 445*290*405mm |
| Net Weight | ≤27kg |
- Stainless steel 316L Enclosure
- Ingress protection IP68
- Resolution 4MP Starlight Level
- 4.5-148.5mm Vari-focal lens
- 33X Optical Zoom, 16x Digital Zoom
- Pan 0-360°, Tilt -90°~+90° Rotation speed: 0.1-45°/s adjustable
- IR Range up to 150meters (300meters is optional)
- AC110-240V Standard (AC30V, DC24V, POE++ Optional)
- Verification to: BS EN 62676-1-1-2014-Video surveillance systems for use in security applications
You can have the product replaced within 7 days due to quality problem and the quality guarantee period for this product is one year. You can also get the favorable promotions.
In the following conditions the product is not considered within the quality guarantee scope:
- Client cannot bring forth the quality guarantee card and invoice or receipt of purchasing
- Improper service conditions, such as unmatched power, ambient temperature, humidity or lighting caused malfunction
- Malfunction caused by accident, negligence, disaster incorrect operation or network attack
- Malfunction or damage in installation, repair, modification or dismantle caused by unauthorized personnel
- Out of guarantee period
If you have any dissent on technical service provided by distributor, please lodge a complaint to the customer's service center of Kaidun. The quality guarantee card will be validated only after it's stamped by the after-service provider.
Container Vessel, Bulk Vessel, Oil Tanker, Cruise Vessel, Yacht, Oil/Gas Drilling Platform, Oil Depots, Sea Port
Other application areas: desert drill sites, offshore rigs, mechanical engineering, biogas plants, military, electric power, hydraulic power, railway, metallurgy, natural gas extraction, drilling platform, aerospace, marine, armed police, border defense, vessels, fireworks production, ports etc.
| Camera | |
|---|---|
| Image device | 1/2.7"inch line by line scan 4MP CMOS image sensor |
| Optical double | 33X |
| Focal distance | Electric and dynamic zoom, 4.5~148.5mm |
| Iris diaphragm | F1.65 (W)~F4.7(T) |
| Field of View (H) | 51.4° ~ 2.5° |
| Field of View (V) | 30.3° ~ 1.4° |
| Field of View (D) | 63.2° ~ 3.0° |
| Shutter | Automatic /manual, 1~1/100000s |
| Through the fog | Adaptive fog |
| Noise-signal ratio | >56dB |
| Wide Dynamic | 120dB |
| Minimal Illumination | 0.003lux(F 1.65,AGC ON,color), 0.002lux(F1.65,AG CON,black and white) |
| Switch the mode day and night | Automatic, day, night, switching quantity control |
| 3D positioning | Support |
| Anti-shake | Support |
| Detection Distance | 105-3100m |
| Observe Distance | 40-1260m |
