JC-4000 Ladder Winches Bucket Chain Dredger for Gold Dredging
Price:
$150,000/sets >=1 sets
MOQ:
1
Delivery Time:
Negotiable
Brand:
Keda
Product Description
Ladder Winches JC-4000 Bucket Chain Dredger Sand Washing Gold Panning Dredging Machine
Bucket chain excavating gold dredger designed for efficient sand washing, gold panning, and dredging operations with advanced mining technology.
Basic Parameters
| Model | KD-1 | KD-2 | KD-3 | KD-4 | KD-5 | KD-6 | KD-7 |
|---|---|---|---|---|---|---|---|
| Pontoon Length (m) | |||||||
| A | 13m | 14m | 15m | 16m | 17m | 22m | 24m |
| B | 14m | 14.5m | 15.5m | 17m | 18m | 20m | 22m |
| C | 15.5m | 16m | 16.5m | 18m | 20m | 20m | 22m |
| Width (m) | |||||||
| A | 1.5m | 1.5m | 1.5m | 1.5m | 1.7m | 1.8m | 1.8m |
| B | 1.5m | 1.5m | 1.5m | 1.5m | 1.7m | 1.8m | 1.8m |
| C | 1.7m | 1.7m | 1.7m | 1.7m | 1.8m | 1.8m | 1.8m |
| Conveying Arm Length (sand/small stone/middle stone) | |||||||
| A | 12m/6m | 13m/6m | 14m/8m | 15m/10m | 18m/12m | 12m/6m | 12m/6m |
| B | 13m/9m/8m | 13.5m/9.5m/6m | 15m/11m/6m | 16m/12.5m/8m | 18m/14m/12m | 14m/10m/8m | 14m/10m/6m |
| C | 15m/12m/8m/6m | 15.5m/12.5m/9m/6m | 15.5m/12m/8m/6m | 17m/13m/10m/10m | 20m/17m/14m/15m | 15m/10m/6m | 16m/12m/9m/5m |
| Bucket (Pic) | 42-46 | 48-52 | 52-58 | 60-66 | 66-78 | 60-70 | 70-76 |
| Dredging Depth (m) | 4m-4.8m | 4m-6m | 4m-7.5m | 4m-10m | 4m-12m | 8m-14m | 8m-16m |
| Output m³/h | 60-100m³ (adjustable) | ||||||
| Power | 1105-1100 | 1110-1100 | 1115-1100 | 1110-1100 | 1115-1100 | 1100-4100 | |
Product Description
The Bucket Chain Gold Dredger is advanced mining equipment featuring cutting-edge technology, rational structure, reliable performance, and easy operation and maintenance. Years of field testing prove its advantages of high mechanization, large output, low investment, and high profitability.
Product Images
Customer Visiting
Company Information
Qingzhou Keda Mining Machine Co., Ltd.
Main Products:
- Gold Extraction Equipment
- Dredger
- Sand Processing Equipment
- Iron Extraction Equipment
Certificate
Why Choose Us
- We are the manufacturer - All machinery is produced in-house, ensuring lower prices, guaranteed quality, and reliable after-sales service.
- Customer satisfaction focus - Producing high-quality, reliable machines is our top priority as our success depends on customer satisfaction.
- Free training & service - Includes free training, installation support, maintenance assistance, and one-year warranty with readily available spare parts.
- New business support - We provide complete design schemes, spot inspections, operator training, and equipment selection guidance.
- Custom recommendations - We'll recommend the most suitable equipment type and provide competitive quotations.
Quality Warranty
12 months warranty coverage for:
- Main parts: Diesel engines, generators, gear boxes, dredge pumps, and hydraulic systems
- All new installed component parts
- Hull and all fabricated parts
Note: Wearing parts are not included in the warranty.
