Energy Saving Gravity Separator with 220V/380V Voltage and 5600*1850*860mm Dimension for Efficient Jig Mining Equipment
Price:
$2,500/sets 1-3 sets
MOQ:
1
Delivery Time:
Negotiable
Brand:
Keda
Product Description
Efficient Diamond Washing Plants and Jig Separators
Gravity Separator Diaphragm Jig / Jig Mining Equipment / Jigger Separator
KDTT jigging machine is an effective and energy-saving gravity separation device designed for optimal recovery of various minerals, especially gold and diamond. Its innovative water flow system ensures superior performance compared to traditional jigging machines.
Key Features
- Compact structure with small footprint
- Energy efficient continuous operation
- High recovery rate with low water consumption
- Simple installation and minimal maintenance
- Adjustable stroke and frequency settings
Technical Specifications
| Item | JT-0.57 | JT1-1 | JT2-2 | JT3-1 | JT4-2 | JT5-2 |
|---|---|---|---|---|---|---|
| Jig room (L*W mm) | 450-750*950 | 450-900*1500 | 1070*1070 | 960-2000*1950 | 1510*1510 | 1200-2000*3150 |
| Max grain size (mm) | 6 | 5 | 10 | <20 | 8 | 8 |
| Capacity (t/h) | 1-2.5 | 2-3 | 4-8 | 10-15 | 12-16 | 20-25 |
| Water consumption (m³/h) | 1-2 | 2-3 | 2-4 | 3-6 | 4-8 | 5-10 |
| Motor power (kW) | 1.5 | 2.2 | 3 | 5.5 | 7.5 | 7.5 |
Manufacturer Information
Qingzhou Keda Ore Machinery Co., Ltd. is an ISO9001:2008 certified manufacturer specializing in mining equipment. Our patented gold wash plants are unique in China, developed through professional engineering and technical expertise.
Product Range
- Gold wash plants series: Capacity from 5-500 tons/hour, including wet and dry configurations
- Dredgers series: Various types for mining, sand production, and land reclamation
- Crusher series: Including hammer, impact, and jaw crushers
Packaging & Shipping
Packaging
- FLC & LCL export standard containers (20/40 GP)
- Steel support with iron sheet sea-worthy packaging
Transportation
- Sea freight with major shipping lines
- Air delivery services available
- Advance notification before vessel arrival
Frequently Asked Questions
To provide accurate recommendations, please specify:
- Intended use (land or river operation)
- Gold particle size (mm)
- Presence of clay/stone and maximum stone diameter
- Water distance for land operations
Contact Information
Company:
Qingzhou Keda Mining Machine Co., Ltd.
Contact:
Fergie Wu
Email:
sales08(at)miningmachine.net
Phone:
+86-18353690657 (Mobile/WhatsApp)
Tel/Fax:
+86-536-2105419
