10kV Power On Off Small Relay 10kV 1 Pole 3A G5NB-1A-E-24VDC
| Attribute | Value |
|---|---|
| Category | Relays |
| Manufacturer | Omron |
| Series | G5NB |
| Mounting Type | Through Hole |
| Coil Voltage | 24VDC |
| Contact Rating (Current) | 5 A |
| Switching Voltage | 250VAC, 30VDC - Max |
| Operating Temperature | -40°C ~ 70°C |
The G5NB-1A-E-24VDC power relay is a compact 1-pole 3A on-off relay featuring exceptional 10kV impulse voltage resistance. Designed with high-power electromagnetic circuits, it achieves high sensitivity (200mW) while maintaining robust performance.
- Certified to UL, CSA, and VDE standards
- Complies with EN61010 reinforced insulation requirements
- PWM drive capability (-PW models) reduces coil holding current
- Sealed construction with flux protection
- Fast operate and release time (10 ms each)
Actual Load Life (Reference Values):
- 120 VAC motor and lamp load: 250,000 operations min. at 23°C
- 160 VDC valve load (with varistor): 250,000 operations min. at 23°C
- 140 VAC pump load: 200,000 operations min. at 23°C
- 100 VAC motor load: 200,000 operations min. at 23°C
Standard export packaging available. Customers can choose from cartons, wooden cases, and wooden pallets according to their requirements.
We typically provide quotations within 24 hours of receiving your inquiry (excluding weekends and holidays). For urgent requests, please contact us directly.
Delivery times vary by order quantity and season. Small batches typically ship within 7-15 days, while large orders may require approximately 30 days.
Standard terms: 30% deposit, with 70% balance paid via T/T before shipment.
We offer sea, air, and express shipping options (EMS, UPS, DHL, TNT, FEDEX). Please confirm your preferred method before ordering.
