LPC1788FBD208K 32-bit ARM Cortex-M3 Microcontroller Up To 512 KB Flash And96 KB SRAM USB Device/Host/OTG Ethernet LCD EMC
LPC1788FBD208K 32-bit ARM Cortex-M3 Microcontroller Up To 512 KB Flash And96 KB SRAM USB Device/Host/OTG Ethernet LCD EMC
- Functional replacement for the LPC23xx and LPC24xx family devices.
-
System:
- ARM Cortex-M3 processor, running at frequencies of up to 120 MHz. A Memory Protection Unit (MPU) supporting eight regions is included.
- ARM Cortex-M3 built-in Nested Vectored Interrupt Controller (NVIC).
- Multilayer AHB matrix interconnect provides a separate bus for each AHB master. AHB masters include the CPU, USB, Ethernet, and the General Purpose DMA controller. This interconnect provides communication with no arbitration delays unless two masters attempt to access the same slave at the same time.
- Split APB bus allows for higher throughput with fewer stalls between the CPU and DMA. A single level of write buffering allows the CPU to continue without waiting for completion of APB writes if the APB was not already busy.
- Cortex-M3 system tick timer, including an external clock input option.
- Standard JTAG test/debug interface as well as Serial Wire Debug and Serial Wire Trace Port options.
- Embedded Trace Macrocell (ETM) module supports real-time trace.
- Boundary scan for simplified board testing.
- Non-maskable Interrupt (NMI) input.
| Part Number | Package Type | Leads/Balls | Body Dimensions | SOT Code |
|---|---|---|---|---|
| LPC1788FBD208 | LQFP208 plastic low profile quad flat package | 208 leads | 28 28 1.4 mm | SOT459-1 |
| LPC1788FET208 | TFBGA208 plastic thin fine-pitch ball grid array package | 208 balls | 15 ´ 15 ´ 0.7 mm | SOT950-1 |
| LPC1788FET180 | TFBGA180 thin fine-pitch ball grid array package | 180 balls | 12 ´ 12 ´ 0.8 mm | SOT570-3 |
| LPC1788FBD144 | LQFP144 plastic low profile quad flat package | 144 leads | 20 20 1.4 mm | SOT486-1 |
| LPC1787FBD208 | LQFP208 plastic low profile quad flat package | 208 leads | 28 28 1.4 mm | SOT459-1 |
| LPC1786FBD208 | LQFP208 plastic low profile quad flat package | 208 leads | 28 28 1.4 mm | SOT459-1 |
| LPC1785FBD208 | LQFP208 plastic low profile quad flat package | 208 leads | 28 28 1.4 mm | SOT459-1 |
| LPC1778FBD208 | LQFP208 plastic low profile quad flat package | 208 leads | 28 28 1.4 mm | SOT459-1 |
| LPC1778FET208 | TFBGA208 plastic thin fine-pitch ball grid array package | 208 balls | 15 ´ 15 ´ 0.7 mm | SOT950-1 |
| LPC1778FET180 | TFBGA180 thin fine-pitch ball grid array package | 180 balls | 12 ´ 12 ´ 0.8 mm | SOT570-3 |
| LPC1778FBD144 | LQFP144 plastic low profile quad flat package | 144 leads | 20 20 1.4 mm | SOT486-1 |
| LPC1777FBD208 | LQFP208 plastic low profile quad flat package | 208 leads | 28 28 1.4 mm | SOT459-1 |
| LPC1776FBD208 | LQFP208 plastic low profile quad flat package | 208 leads | 28 28 1.4 mm | SOT459-1 |
| LPC1776FET180 | TFBGA180 thin fine-pitch ball grid array package | 180 balls | 12 ´ 12 ´ 0.8 mm | SOT570-3 |
| LPC1774FBD208 | LQFP208 plastic low profile quad flat package | 208 leads | 28 28 1.4 mm | SOT459-1 |
| LPC1774FBD144 | LQFP144 plastic low profile quad flat package | 144 leads | 20 20 1.4 mm | SOT486-1 |
