IP67 Circular M12 Connectors Angled 4 Pin Male Full Metal Field Assembled Contact
Price:
Negotiable
MOQ:
50 pieces
Delivery Time:
5-8 working days
Brand:
KRONZ
Product Description
M12 Angled Circular Connector 4 Pin Male Full Metal Field-assembled Contact
Product Overview
The M12 4-pin male connector features a 90° angled design with full metal housing, engineered for superior durability in demanding industrial environments. Its rugged construction provides exceptional resistance to vibration, impact, and corrosion, while the IP67/IP68-rated sealing ensures reliable protection against dust and moisture ingress.
Technical Specifications
| Standard | IEC 61076-2-101 |
|---|---|
| Contact nut material | Brass, nickel-plated |
| Contact surface material | Brass, gold-plated |
| Contact carrier material | PA, black |
| Housing material | Zinc alloy, nickel-plated |
| Seal material | FPM/FKM |
| Insulation resistance | ≥100MΩ |
| Contact resistance | ≤5mΩ |
| Pollution degree | 3 |
| Ambient temperature | -25~+85℃ |
| Mating cycles | >100 |
| Degree of protection | IP67 |
Configuration Details
| Pin assignment |  |
|---|---|
| Connection method | Screw connection |
| Coding | A |
| Rated current | 4A |
| Voltage | 250V |
| Cable outlet | Angled |
| External cable diameter | 4-8mm |
| Model No. | H1204MAV-0 |
Key Features
- Full metal housing for maximum durability
- 90° angled design for space-saving installation
- IP67/IP68 protection against harsh environments
- Screw connection for secure cable termination
- Field-assembled for flexible installation
- 4-pin configuration with gold-plated contacts
