Industrial 480W Din Rail Mounted Power Supply 20A / 24V PLC Power Supply
Price:
Negotiable
MOQ:
5 pieces
Delivery Time:
5-8 working days
Brand:
KRONZ
Product Description
DIN Rail Power Supply 480W 24V/20A For PLC
Product Overview
Industrial-grade 480W AC/DC power supply designed for industrial automation applications. This DIN rail-mounted unit provides high stability and anti-interference power for control equipment in harsh environments.
Key Features
- Universal input voltage: 85-264VAC/120-370VDC
- High efficiency up to 94% with active PFC (PF > 0.95)
- 3000VAC high isolation withstand voltage
- Comprehensive protection: short circuit, over-current, over-voltage, over-temperature
- Compact design (48mm width) with DIN rail mounting (TS-35/7.5/15)
- Wide operating temperature range: -30℃ to +70℃
- Low ripple noise and DC OK function
- Meets IEC/EN safety standards with good EMC performance
Technical Specifications
| Attribute | Value |
|---|---|
| Output Power | 480W |
| Output Voltage | 48-55V |
| Max. Capacitive Load | 2700μF |
| Leakage Current | 240VAC |
| Cooling Method | Free air convection |
| Mounting Type | DIN-Rail |
Detailed Specifications
Input Specifications
| Item | Operating Conditions | Min. | Typ. | Max. | Unit |
|---|---|---|---|---|---|
| Input Voltage Range | AC input | 85 | --- | 264 | VAC |
| Input Current | 230VAC | --- | --- | 2.5 | A |
| Power Factor | 230VAC | 0.95 | --- | --- | --- |
Output Specifications
| Item | Operating Conditions | Min. | Typ. | Max. | Unit |
|---|---|---|---|---|---|
| Output Voltage Accuracy | Full load range | --- | ±1.0 | --- | % |
| Ripple & Noise | 20MHz bandwidth (peak-peak value) | --- | --- | 120 | mV |
| Over-voltage Protection | 48V | 56V-60V | --- | --- | --- |
Physical Characteristics
| Item | Value |
|---|---|
| Dimensions | 131.50 x 48.00 x 125.00 mm |
| Weight | 980g (Typ.) |
| Case Material | Metal (AL1100, SPCC) and Plastic (PC940) |
EMC Characteristics
Complies with:
- CE CISPR32/EN55032 CLASS B
- IEC/EN 61000-3-2 CLASS A and CLASS D
- IEC/EN 61000-4-2 Contact ±6KV/Air ±8KV
- IEC/EN 61000-4-5 line to line ±2KV/line to ground ±4KV
