13.3-Inch Large FHD Outdoor Display | 1920×1080 Resolution, EDP Interface, 1000cd/m² High Brightness for Outdoor Kiosks & Street-Level Digital Signage
Price:
$10-50
MOQ:
1000
Delivery Time:
4~6weeks
Brand:
HuaXin
Product Description
13.3-Inch Large FHD Outdoor Display
High-performance 1920*1080 resolution TFT module with EDP interface and 1000cd/m² brightness, ideal for outdoor kiosks and street-level digital signage applications.
Key Specifications:
| Part No. | ESHX133FHM-N81 |
| Display Technology | TFT module |
| Display Size | 13.3 inch |
| Resolution | 1920*1080 |
| Interface | EDP |
| View Angle | 89/89/89/89 (U/D/L/R) |
| Brightness | 1000cd/m² |
| Touch Screen | Optional |
| Working Temperature | -20°C to 70°C |
| Storage Temperature | -30°C to 80°C |
Technical Drawing:
-
TFT Product KnowledgeTFT Substrate Input and CF Substrate Input Flow Chart
![TFT substrate input flow chart]()
TFT Structure![TFT structure diagram]()
Our advantage- Founded in 2009 in Hubei Enshi, specializing in LCD, LCM, TFT, backlight, and OLED research, development, and production.Product range includes VA, TN, HTN, STN, FSTN, CSTN LCDs and COB, TBA, COG, TP, LED backlight LCMs.
- Registered capital: 20 million | Staff: 500+ (10% R&D, 15% QC)
-
Certifications: ISO14001, ISO9001/IATF16949, SGS
-
Cost-effective production base located in inland city
•Advanced equipment ensuring stable quality
• Highly automated processes for efficiency and consistency
• Experienced engineering team with 20+ years in LCD field
•Custom product design capabilities
Product Applications- Car navigation & printer
- Video call & advertising
- Automotive & medical devices
- Fitness equipment & handheld devices
- Industrial control and home appliance
![]()
