7 Inch Round TFT LCD Display 1080x1080 Full HD - MIPI Interface 800 CD/m² High Brightness - Wide Viewing Angle for Smart Home/Gadgets

Price Negotiable
Price: $17.3-$50
MOQ: 1000
Delivery Time: 4~6weeks
Brand: HuaXin
Product Description
HX070R-40MT-A1 is  7-inch round TFT display is a high-performance visual solution designed for diverse smart devices and industrial applications. With Full HD 1080x1080 resolution, MIPI DSI interface, and 800 CD/m² (nits) high brightness, it delivers clear, vivid images even in bright environments, meeting the demands of both consumer electronics and professional equipment.

Key Specifications
Part NO. HX070R-40MT-A1
Display Type 7 inch Round TFT display module
Resolution 1080x1080
Panel Size(mm) 192.75(H)*191.58(V)*4.75(D)
Active Area (mm) 177.55 (H)*177.55 (V)
View direction ALL
interface MIPI
Driving IC FL5893DC
brightness 800c/d

Technical Drawing
TFT Product Knowledge
TFT Substrate Input and CF Substrate Input Flow Chart
TFT substrate input flow chart
TFT Structure
TFT structure diagram
 Our advantage
  • Founded in 2009 in Hubei Enshi, specializing in LCD, LCM, TFT, backlight, and OLED research, development, and production.Product range includes VA, TN, HTN, STN, FSTN, CSTN LCDs and COB, TBA, COG, TP, LED backlight LCMs.
  •  Registered capital: 20 million | Staff: 500+ (10% R&D, 15% QC)
  •  Certifications: ISO14001, ISO9001/IATF16949, SGS

  • Cost-effective production base located in inland city

    •Advanced equipment ensuring stable quality

    • Highly automated processes for efficiency and consistency

    • Experienced engineering team with 20+ years in LCD field

     •Custom product design capabilities

Product Applications
  • Car navigation & printer
  • Video call & advertising
  • Automotive & medical devices
  • Fitness equipment & handheld devices
  • Industrial control and home appliance
