5.2 Inch Lcd Bar Screen TFT Color LCD Display 416X1280 Dots LVDS Interface Driving IC JD9161Z
Price:
$6~$100
MOQ:
1000
Delivery Time:
4~6weeks
Brand:
HuaXin
Product Description
5.2 Inch LCD Bar Screen TFT Color LCD Display
High-resolution 416x1280 dot display with MIPI interface and JD9161Zdriving IC, featuring all-view angle capability.
Key Specifications:
| Part No: | HX052BFW8931ANT |
| Size | TFT LCD 5.2 inch |
| Resolution | 416X1280 |
| Brightness(cd/m2) | 400c/d |
| Active Area | 40.75*125.38mm |
| Outline dimension | 43.55*131.28*2.08mm |
| Interface | MIPI |
| View Angle | ALL |
| Operating temperature | -20~70 |
| driving IC | JD9161Z |
Technical Drawing
TFT Product Knowledge
TFT Substrate Input and CF Substrate Input Flow Chart
TFT Structure
Our advantage
- Founded in 2009 in Hubei Enshi, specializing in LCD, LCM, TFT, backlight, and OLED research, development, and production.Product range includes VA, TN, HTN, STN, FSTN, CSTN LCDs and COB, TBA, COG, TP, LED backlight LCMs.
- Registered capital: 20 million | Staff: 500+ (10% R&D, 15% QC)
-
Certifications: ISO14001, ISO9001/IATF16949, SGS
-
Cost-effective production base located in inland city
•Advanced equipment ensuring stable quality
• Highly automated processes for efficiency and consistency
• Experienced engineering team with 20+ years in LCD field
•Custom product design capabilities
Product Applications
- Car navigation & printer
- Video call & advertising
- Automotive & medical devices
- Fitness equipment & handheld devices
- Industrial control and home appliance
