Modified PPO N9F20LH Resin Granules For Fields Such As Fluid Engineering, Electronics And Electrical, Mechanical, Etc.UL94 HB@3mm For Injection Molding
Modified PPO N9F20LH
N9F20LH Modified PPO 20% GF, suitable for fields such as fluid engineering, electronics and electrical, mechanical,etc.
Application
Main physical property
| Test Item | Test Method | Unit | Value | |||
| Melt Index (280℃, 5kg) | ASTM D1238 | g/10min | 8.6 | |||
| Density | ASTM D792 | g/m³ | 1.22 | |||
| Tensile strength | ASTM D638 | Mpa | 94.1 | |||
| Elongation at Break | ASTM D638 | % | —— | |||
| Bending strength | ASTM D790 | Mpa | 146.8 | |||
| Bending modulus | ASTM D790 | Mpa | 5510 | |||
| Izod notched impact strength (23℃) | ASTM D256 | J/m | 138 | |||
| Heat Distortion Temp (0.45MPa) | ASTM D648 | ℃ | 139 | |||
| Flame retardant grade (3mm) | UL 94 | Class | HB | |||
| Flame retardant grade (0.76mm) | ASTM D257 | |||||
| Shrinkage | ASTM D955 | % | 0.2-0.4 | |||
For more information please download the datasheet
Get The Latest Quotation
|
 |
We also provide certificates including: Halogen-Free Certification,UL Yellow Card,Oxygen Index,Smoke Density,Glow-Wire Ignition (GWI) Certificat.
Why Choose Us
Our company possesses a dedicated R&D team that develops customized solutions based on client requirements. We rapidly provide material samples for testing, meeting the demands of new product development.
Our professional testing personnel conduct full-range performance testing on every batch of products. A performance test report is provided with all outgoing shipments, ensuring high and assured quality!
Click to consult and get the latest quotation(within 24 hours!)
1.Speed advantage
Professional engineer service team with more than 15 years of experience; Provide a complete set of solutions and services from material sales, quality appraisal, mold design, molding and processing.
2.Small batch type selection technical support
Accept small batch orders of 5kg at least; The rofessional engineer team can cooperate with customers to carry out material selection in the early stage of production, and provide corresponding material recommendations ccording to customer production and product requirements
3. Quality assurance
Our products are all from well-known manufacturers. Each batch of materials has various inspection reports and certificates including original factory certificate, MSDS, ROHS, SGS, reach,, EU, UL, COC / COA, etc.
Unlock Your Material Solution - Contact Us!
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
