Used ACME CM-S6 BSW Moving Head With Integrated Beam Dye And Other Functions
Price:
$100-200
MOQ:
1
Delivery Time:
5
Brand:
ACME
Product Description
ACME CM-S6 with Integrated Beam, Dye, and Multi-Effect Functions
The ACME CM-S6 integrates multiple lighting effects including beam, wash, pixel effects, starry sky background, and moon flower beam. Designed for professional performance venues, it delivers powerful optical effects with flexible beam control for TV shows, concerts, and dance halls.
Key Features
- 36 (6x6) x 15W RGBW single-point controllable LEDs + 49 (7x7) white LEDs for starry sky effect
- Preset matrix effects with various graphic patterns
- Precision RGBW color mixing with CTO temperature adjustment (2500K-8000K)
- 0-100% smooth dimming with flicker-free HD camera operation
- Variable speed strobe effects including random strobe and pulse modes
- Advanced thermal management with auto-adjusting fan speed
- Optional reflector module for moon-shaped beam effects
- 16-bit scanning precision for X/Y axis movement
Technical Specifications
| Light Source | |
|---|---|
| Light Source | 36 x 15W RGBW LEDs + 49 x 0.06W White LEDs |
| Luminous Flux | 9,600 lumens |
| LED Lifespan | 20,000 hours (manufacturer data) |
| Optical System | |
| Beam Angle | 6° |
| Color Mixing | RGBW + White Starry Sky Effect |
| Dimming | 0-100% smooth dimming (16-bit) |
| Control System | |
| Control Protocols | DMX512, RDM, Art-Net |
| DMX Channels | 21/166/206 channel modes |
| Interface | 3-pin/5-pin XLR, RJ45 |
| Physical Specifications | |
| Dimensions | 575mm × 466mm × 246mm (22.6" × 18.3" × 9.6") |
| Weight | 20kg (44lbs) |
| Mounting | Horizontal/vertical operation, 1/4-turn locks, 50mm truss hooks |
| Electrical | |
| Power | 580W @ 180-240V 50/60Hz |
| Operating Temp | 0°C to 40°C (max surface temp 65°C) |
| Certifications | CE Certified |
Optional Accessories
- Reflector module: 3005003101
- Rain cover: 3033001749
- Flight case (4-in-1): 3205001189
- Light hook: 2060001635 (C-100A)
- Safety cable: 2060000200-B (SW-02)
