Second-hand ACMEMC560Z Two-tone Blade Stage Beam Light In New Condition 27/70/55 Control Channel
Price:
$322
MOQ:
1
Delivery Time:
5
Brand:
ACME
Product Description
ACMEMC560Z Two-Tone Blade - New Condition
Dual-Purpose Effects Fixture
The ACME GEMINI fixture combines pan/tilt zoomable color light bar and high-power strobe functionality in a compact luminaire. Featuring five 60W RGBW LEDs in the front section and 36 cool white LEDs in the rear strobe section (41,000 lumens output), this versatile unit delivers exceptional lighting effects for any production.
Key Features
- Dual-function design: color light bar and strobe in one unit
- 5 x 60W RGBW LEDs (front) + 36 x 18W CW LEDs (rear strobe)
- 41,000 lumens total output
- Zoom range: 2.8° to 46° (beam/wash), 96° (strobe)
- 7 DMX control modes with preprogrammed colors/macros
- Unlimited pan/tilt operation with 16-bit resolution
- Variable speed strobe and smooth dimming (0-100%)
- Lightweight (19.5kg) and compact design
Technical Specifications
| Model Information | ||
|---|---|---|
| Model Name | GEMINI | |
| Model Code | CM-560Z | |
| Light Source System | ||
| Beam Light Source | 5 x 60W RGBW LED | |
| Strobe Light Source | 36 x 18W CW LED | |
| Total Lumen Output | 41,000 lumens | |
| Expected Lifespan | 20,000 hours | |
| Optical System | ||
| Beam Angle (Beam/Wash) | 2.8° - 31° | |
| Beam Angle (Strobe) | 96° | |
| Field Angle (Beam/Wash) | 5° - 46° | |
| Field Angle (Strobe) | 116° | |
| Control System | ||
| Control Protocols | DMX512, RDM, Art-Net, sACN | |
| DMX Modes | 7 types | |
| Firmware Upgrade | Supported via DMX link | |
| Electrical Specifications | ||
| Input Voltage | 100-240V AC, 50/60Hz | |
| Total Power Consumption | 1,240W | |
| Power Connection | PowerCON input/output | |
| Physical Specifications | ||
| Dimensions (W x D x H) | 130mm x 500mm x 420mm (5.1" x 19.7" x 16.5") | |
| Weight | 19.5 kg (43.0 lbs) | |
| Included Accessories | ||
| 2 omega brackets, power cable, user manual | ||
