Used FINE LINE 1400ZL PERF Protection level IP 20
Price:
Negotiable
MOQ:
1
Delivery Time:
5
Brand:
FINE
Product Description
FINE LINE 1400ZL PERF
Product Overview
The FINE LINE 1400ZL PERF is a high-performance 1400W pattern-imaging and cutting computer light designed for professional rental applications. Featuring advanced technologies including intelligent fan control, encoder positioning, and innovative reflector designs, this unit delivers exceptional lighting performance with over 35,000 lumens output through its 140mm diameter lens. Its modular design allows quick conversion between pattern and cutting lighting configurations, making it ideal for television studios, theaters, and large-scale concert productions.
Key Features
- Magnetic rotary encoder positioning for enhanced accuracy
- Modular design for flexible pattern/cutting light conversion
- Uniform light spot with >80% uniformity
- 8°-50° zoom range with constant beam adjustment
- High CRI (Ra ≥ 95) color rendering
- Advanced CMY color mixing system
- Full graphic shutter system with precise indexing
Technical Specifications
| Optical System | ||
|---|---|---|
| Light Source | OSRAM lok-it 1400-PS_Brilliant (High CRI) Lamp | |
| Reflector | Italian optical coating process | |
| Beam Lens Diameter | 140mm | |
| Total Luminous Flux Output | > 35,000 lm | |
| Spot Uniformity | > 80% | |
| Zoom Range | 8° ~ 50° | |
| Color Rendering Index (CRI) | Ra ≥ 95 | |
| Color System | ||
| Color Mixing | CMY continuous color mixing | |
| CTO (Color Temperature Orange) | Linear adjustment (2700K - 6500K) | |
| Color Wheel | 7 color filters + White. Bidirectional color rainbow, stepping gradients, bidirectional rotation, random color modes. | |
| Gobo System | ||
| Gobo Specifications | Outer Ø: 37.3mm, Thickness: 1.1mm, Pattern Area: Ø26mm, Material: Glass | |
| Rotating Gobo Wheel | 1 wheel with 5 indexable rotating gobos. Effects: rotation, animation, shake. | |
| Effects Wheel | 1 dynamic wheel (can be switched in/out, bidirectional rotation). Optional: replace with fixed gobo wheel (9 patterns). | |
| Shutter / Cut System | ||
| Shutter System | Full graphic shutter system + 90° graphic positioning | |
| Shutter blades with precise indexing | ||
| Effects | ||
| Prism | 1 rotating 4-facet prism, bidirectional rotation | |
| Frost / Diffusion | Independent frost effect | |
| Dimmer | Independent dimmer, 0-100% linear | |
| Strobe | Independent strobe, 1-13 flashes/sec. Pulse, asynchronous, synchronous, random (slow/med/fast) modes. | |
| Iris | Fast motorized iris, 5-100% linear adjustment with macro effects | |
| Electronic Frost | Electronic linear frost via motorized focus, constant beam angle adjustment | |
| Movement (Pan/Tilt) | ||
| Pan | 540°, precision 2.11°/step, micro-precision 0.008° | |
| Tilt | 270°, precision 1.05°/step, micro-precision 0.004° | |
| Positioning System | Non-contact magnetic rotary encoders for Pan and Tilt | |
| Control & Programming | ||
| Control Channels | 32 (Standard) / 35 (16Bit) / 42 (Extended) | |
| Control Protocol | DMX512, Art-Net, Wireless DMX (Optional) | |
| Menu Display | 3.5-inch LCD, 128x64 resolution, Chinese/English, 180° invertible display | |
| Control Method | Contactless scroll wheel | |
| Electronic Features | ||
| Backup Power | Self-charging buffer battery for menu operation when power is off | |
| Energy Saving | Automatic power reduction when shuttered or CMY closed | |
| Fan Control | Intelligent speed regulation | |
| Temperature Control | Electronic temperature sensing | |
| DMX Monitor | DMX channel level monitoring | |
| Info Query | Fixture information query via LCD screen | |
| RDM | Supports bidirectional RDM data transmission | |
| Positioning | Magnetic encoders, signal feedback, absolute position memory, DMX/Offline position restore | |
| Power Supply | ||
| Input Voltage | 200-240V~, 50/60Hz | |
| Ballast | Electronic ballast | |
| Power Consumption | 1800W | |
| Power Factor | PF ≥ 0.98 | |
| Dimensions & Weight | ||
| Fixture Dimensions | 465 x 439 x 777.5 mm | |
| Case Dimensions (Flight Case) | 654 x 524 x 819 mm | |
| Net Weight | 42.5 kg | |
| Gross Weight | 78 kg | |
| Packing | ||
| Flight Case | 1 unit per case | |
| Protection Rating | ||
| IP Rating | IP20 | |
