Outdoor Box Type Substation Compact Substation with 500kva 630kva 800kva Power Transformer
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
HENTG Power
Product Description
Transformer Manufacturer Box Type Substation
Outdoor Power Transformer Compact Substation - 500kVA, 630kVA, 800kVA
High-performance box type substation designed for outdoor power distribution applications. Available in 500kVA, 630kVA, and 800kVA configurations to meet diverse electrical infrastructure requirements.
Key Features:
- Compact and space-saving design for efficient installation
- Robust construction for outdoor durability
- Available in 500kVA, 630kVA, and 800kVA capacity options
- Designed for reliable power distribution in industrial applications
- Complies with industry standards for electrical safety
| Technical Data For YB Pre-installed Substation | |||
| HV | Item | Unit | Date |
| Rated Frequecy | Hz | 50 | |
| Rated Voltage | kV | 6 10 35 | |
| Industrial Requency Voltage-resisting Time / | kV | 32/36 42/48 95/118 | |
| isolationBallisticVoltage-resisting | |||
| Thunder and Lighting Ballistic Voltage-resisting Time /isolation Sectional Port | kV | 60/70 75/85 185/215 | |
| Rated Curent | A | 400 630 | |
| Rated Brief-period Curent-resisting | kA | 12.5(2s) 16(2s) 20(2s) | |
| Rated Crest Value Curent-resisting | kA | 32.5 40 50 | |
| LV | Rated Voltage | V | 380 220 |
| Rated Current Of Major Return Circuit | A | 100-3200 | |
| Branch Circuit | A | 10-800 | |
| Quantity Of Branch | line | 1月12日 | |
| Compensation Circuit | kVAR | 0-360 | |
| Transtorming | Rated Capacity | kVA | 50-2000 |
| Short-circuit lmpendance | % | 4 6 | |
| Scope Of Branch Connection | +2x2.5% ±5% | ||
| Vector Group | Yyn0 Dyn11 | ||
