Quantity(Set)

1 Set

Rated capacity (KVA)

80

Phase

Three phase

Input voltage

Primary/Secondary: 400V L1+L2+L3+N

Output voltage

Primary/Secondary:400VL+L2+L3+N +PE

Rated frequency

50hz/60hz

Short circuit impedance (%)

4

Material

copper wire

Insulation class

H

Primary thread warp (MM)

260mm²

Secondary warp (MM)

150mm²

No-load current(%)

250mA

Insulation level

Phase-to-phase and each phase-to-ground, to iron core pressure:AC:3kV 1min

Measure  with  a  1000V  megohmmeter:  the  phase  of  the winding-ground  ≥200MΩ;  the  core-clamp  and  the  ground ≥2MΩ (remove the grounding plate when measuring)

Core Magnetic Density (T)

14000

Noise (Sound Pressure Level: dB)

≤50 ( 1m away from the body)

Transformer  body  and  output  temperature rise (K)

45K

Cooling method

AN/AF
