Diesel Engine 18 Ton Road Sweeper Truck Sweeper Lorry ZBJ5181TSLD6

Price Negotiable

Price: 6680-7800usd

MOQ: 1 Piece

Delivery Time: 15-45 workdays

Brand: Bioclean

Product Description

ZBJ5181TSLD6 18ton diesel street road sweeper truck

1. Core Functions and Parameters

This vehicle is mainly used for road cleaning. It is equipped with core devices such as a box, a cleaning device assembly and an anti-collision buffer device, which can efficiently clean road garbage.

Only 5300mm wheelbase is used, and there are multiple corresponding combinations of overall dimensions:
9850/5300/1400/3150(mm)
9880/5300/1430/3150(mm)
9905/5300/1455/3150(mm)
8920/5300/1400/2220(mm)
8950/5300/1430/2220(mm)
8975/5300/1455/2220(mm)
9800/5300/1400/3100(mm)

2. Safety Configuration

(1) Protection Devices

The side protection is made of aluminum alloy, connected by bolts, which is stable and reliable.

The lower rear protection is made of Q235B, connected by bolts and welding. Its cross-sectional size is 120×60mm, and the height from the ground is 480mm, which effectively improves operation safety.

(2) Braking System

It is equipped with a variety of optional ABS systems, including 3631010-C2000 and ABS 8 from Dongke Knorr Commercial Vehicle Brake System (Shiyan) Co., Ltd., ABS-E 4S/4M from ZF Commercial Vehicle System (Qingdao) Co., Ltd., and J ABS from Jiaozuo Boruike Control Technology Co., Ltd., which can effectively improve braking stability.

3. Optional Configurations

A speed limiting device can be optionally installed, with a speed limit of 89km/h, which conforms to road driving regulations.

The upper installation style can be optionally selected, which can be flexibly chosen according to actual needs to meet the appearance and functional requirements of different operation scenarios.

4. Application Scenarios

With professional cleaning devices, stable performance and various size options, this vehicle is suitable for cleaning operations on various roads. It can efficiently deal with different road environments and provide reliable guarantee for road cleaning.

parameters:

Item	ZBJ5181TSLD6
Energy type	Diesel
Dimension(L x W x H)	9850,9880,9905,8920,8950,8975,9800×2550×3400,3450,3350,3270,3300(mm)
Chassis	DFH1180EX8
Engine	D6.7NS6B260
Curb Weight	14080,14500,13700(Kg)
Rated Loading	3790,3725,3370,3305,4170,4105(Kg)
Total Mass	18000(Kg)
Max.Speed	89,98(km/h)
Sweeping Width	2.5m
Sweeping Efficiency	93%
Maximum Sweeping Speed	20kmh
Maximum Inhaled Particles	110mm
