Large Capacity 20 Tons Automatic Transfer Trolley For Handling Heavy Material
Price:
US$3000-3500
MOQ:
1 Piece
Delivery Time:
15-25 days
Brand:
BETTER
Product Description
Large Capacity 20 Tons Automatic Transfer Trolley
This intelligent heavy material transfer equipment features a 20-ton rated load capacity and advanced automation for industrial applications.
Key Specifications
Load Capacity: 20 tons
Navigation: Laser SLAM natural navigation with obstacle avoidance
Drive System: High-power servo motors with heavy-duty wheels
Power System: Lithium iron phosphate battery with automatic charging
Control System: Intelligent controller with central dispatch integration
Navigation: Laser SLAM natural navigation with obstacle avoidance
Drive System: High-power servo motors with heavy-duty wheels
Power System: Lithium iron phosphate battery with automatic charging
Control System: Intelligent controller with central dispatch integration
Core Functions
- Fully automated unmanned handling with automatic loading, transportation, and unloading
- Intelligent path planning and real-time obstacle avoidance using laser radar
- High-precision positioning for automatic docking with production lines and equipment
- Multi-vehicle collaboration and traffic control through central dispatch system
Safety Configuration
- 360° safety protection with front/back laser radars and side sensors
- Mechanical anti-collision strips for physical contact protection
- Sound and light warning system for operation alerts
- Multiple emergency stop buttons and remote emergency stop capability
Customization Options
- Vehicle platform integration with power drum lines, chain plates, or lifting platforms
- Special environment versions: Cleanroom, explosion-proof, and high/low temperature
- Optional hydraulic lifting or platform rotation functions
- T-slot platforms and specialized fixtures for specific applications
Product Parameters
| Model | BXC-2t | BXC-5t | BXC-10t | BXC-16t | BXC-20t | BXC-25t | BXC-30t | BXC-40t | BXC-50t | BXC-63t | BXC-80t | BXC-100t | BXC-150t | |
| Rated Load(t) | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
| Table Size (mm) | Length(L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| Width(W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
| Height(H) | 450 | 500 | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
| Wheel Base(mm) | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
| Wheel Diameter (mm) | 270 | 270 | 300 | 350 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
| Running Speed (m/min) | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Total Power(kw) | 2 | 3 | 2.2 | 2.2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | |
| Battery Capacity(Ah) | 150 | 180 | 180 | 200 | 220 | 220 | 260 | 300 | 330 | 400 | 400 | 440 | 600 | |
| Battery Voltage(V) | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
| Running Time When Full Load | 4.32 | 5.4 | 4.8 | 4.3 | 4 | 4 | 3.5 | 3.6 | 3.3 | 3 | 3.6 | 3.2 | 2.9 | |
| Running Distance for One Charge(km) | 6.5 | 8.1 | 7.2 | 5.1 | 4.8 | 4.8 | 4.2 | 4.3 | 4 | 3.6 | 4.3 | 3.8 | 3.2 | |
| Max Wheel Load(KN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
| Recommended Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 | |
Applications
Suitable for intelligent scenarios requiring frequent transfer of large-tonnage materials:
- Automobile and component manufacturing: Engine, gearbox, and body assembly transfer
- Heavy machinery manufacturing: Large welding parts, molds, and structural components
- Steel and non-ferrous metals: Steel coils, plates, and ingots distribution
- New energy and battery manufacturing: Heavy-duty battery modules and PACK packages
- Intelligent Warehousing: Automated inbound/outbound storage and internal transportation
Common Applications
- Coil handling with V-Groove deck
- Tank transportation for uniformly distributed loads
- Assembly line shuttle for complete builds or partial products
- Maintenance cart for motors and pumps
- Equipment support with stand-off deck
- Material shuttle for steel tubing with guard rails
- Elevating platform for assembly processes
- Sand casting transportation with flat decking
Customization Information
For custom solutions, please provide:
- Load type and product specifications
- Maximum weight and dimensions (Length × Width × Height)
- Operational requirements: Trip time, frequency, and shifts per day
- Travel area details: Rail/floor type, indoor/outdoor, travel path
- Distance to travel and any special environmental conditions
Our Advantages
Low Noise Operation
Minimal noise levels for improved workplace environment
Maximum Safety
Comprehensive safety features protecting operators and materials
Easy Operation
User-friendly design with immediate operational capability
Easy Implementation
Operates on standard floors without complex installation
Versatile Capacity
Suitable for loads from small to extremely large (up to 300 tons)
Packaging & Shipping
Standard Shipping: Equipment under 6m length and 2.2m width shipped via 20ft container
Large Equipment: 5.9m-12m length shipped via 40ft container
Oversized Equipment: Beyond standard dimensions shipped via flat rack or bulk cargo
Multiple Units: 2-3 sets shipped via full container; single sets via LCL container
Large Equipment: 5.9m-12m length shipped via 40ft container
Oversized Equipment: Beyond standard dimensions shipped via flat rack or bulk cargo
Multiple Units: 2-3 sets shipped via full container; single sets via LCL container
