Waterproof Motorcycle Electric Fast Charging Stations 4KW Four Channel
Price:
1100-1770usd/set
MOQ:
1-50 sets
Delivery Time:
20-30 days
Brand:
GT
Product Description
High Power Fast Charging Pile for Electric Tricycles 4KW Four-Channel
High Power Charging Pile for Electric Tricycles 4KW Four-Channel Fast Charging Solution
The power swap cabinet is a power swap system specially designed for electric low-speed vehicles (such as electric tricycles, electric motorcycles, electric low-speed four-wheelers, etc.). The system allows users to quickly replace a depleted battery with a fully charged one without having to wait for a lengthy charging process.
Product Parameters
| Number of equipment output channels | Four Connector (4KW) |
|---|---|
| Input voltage range | Single-Phase Electricity AC 220V±20% |
| Input voltage frequency | 50HZ ±1HZ |
| Total output power | 16KW |
| Single output power | 4KW |
| Output voltage range (DC) | 30V-100V |
| Single maximum output current range | 65A |
| Battery BMS communication | CAN/RS485 |
| How to use | Scan Code/Card Swipe |
| Communication method | 4G |
| Display | 7-inch Industrial Touch Screen |
| Cooling method | Temperature Controlled Air Cooling |
| Temperature control | Yes |
| Battery BMS monitoring | Yes |
| Battery abnormal warning | Yes |
| Charging connector | Four * 3m |
| Protection | Overload, Overvoltage, Undervoltage, Overcurrent, Leakage, Water Immersion, Lightning Protection, Etc |
| Material and craftsmanship | Thickened Cold-rolled Steel Plate |
| Appearance and craftsmanship | Electrostatic Spraying |
| Protection level | Dustproof And Waterproof IP53/IP54 |
| Charging port | GB/T 20234.2-2015 |
Key Features
Quick battery replacement: Designed to achieve quick battery replacement, greatly shortening the user's waiting time.
Intelligent management: Built-in intelligent management system can monitor the status of each battery, including remaining power, health status, etc., ensure charging safety, and automatically sort and distribute batteries.
Safe and reliable: Multiple safety mechanisms are adopted to ensure the safety of personnel and equipment during battery replacement and prevent overcharge, short circuit and other problems.
Easy to operate: Usually equipped with a touch screen or mobile phone application to guide users to simple and intuitive operations.
Energy saving and environmental protection: Helps reduce the power waste caused by battery charging while extending battery life.
Network connection: Supports networking function, which can remotely monitor and manage the situation of each battery swap station.
