AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm HYDROGEN CG AS 1531 Overall Head Bare Conductor
TECHNICAL SPECIFICATION AND PACKING DETAIL
(HYDROGEN CG)
Description: Overhead AAAC conductor which is used for aerial power networks is suitable for aerial installation between poles.
Construction: The metallic conductor (AAAC) is consisted of aluminum alloy wires. The interstices of the inner layers are filled by grease compound which is suitable for the operating conditions of the conductor.
Standard: AS1531
AAAC Cross section diagram
HYDROGEN CG
Properties of AAAC 7/4.5mm
Some not mentioned, please see AS1531.
PACKING DETAIL
Conductors shall be wound on a non-returnable fumigated drum or metal drum. The
required marking shall be printed with a weather-proof material on the outsides of drum
according to customer's requirement.
![AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor]()
![AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor]()
![AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor]()
![AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor]()
![AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor]()
![AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor]()
![AAAC 1120 Aluminum Alloy Conductor 7/4.5 mm Hydrogen Cg as 1531 Overall Head Bare Conductor]()
TECHNICAL SPECIFICATION AND PACKING DETAIL
(HYDROGEN CG)
Description: Overhead AAAC conductor which is used for aerial power networks is suitable for aerial installation between poles.
Construction: The metallic conductor (AAAC) is consisted of aluminum alloy wires. The interstices of the inner layers are filled by grease compound which is suitable for the operating conditions of the conductor.
Standard: AS1531
AAAC Cross section diagram
HYDROGEN CG
Properties of AAAC 7/4.5mm
| ITEM | DESCRIPTION | UNIT | TECHNICAL PARTICULARS |
| 1 | Code name | - | HYDROGEN CG |
| 2 | Applicable Standards | - | AS1531 () |
| 3 | Type of conductor | - | AAAC |
| 4 | Properties of Aluminum 1120 wires | ||
| Nominal Diameter | mm | 4.50 | |
| Max. | mm | 4.545 | |
| Min. | mm | 4.455 | |
| Cross-sectional area | mm2 | 15.90 | |
| Approx. Mass | Kg/km | 42.9 | |
| Min. breaking load | kN | 3.66 | |
| Minimum ultimate tensile stress | MPa | 230 | |
| Maximum DC resistance at 20ºC 20ºC | Ω/km | 1.84 | |
| 5 | Properties of Grease | ||
| Type of grease | Anti- Corrosion | ||
| Color of grease | Offwhite | ||
| Drop point of grease(min.) | ºC | 120 | |
| Approx. mass(NOMINAL) | Kg/km | 3.04 | |
| 6 | Properties of Stranded conductor | ||
| Stranding and wire diameter: Aluminum wire / | 7/4.50 | ||
| Lay length of outermost layer | times | 168(-0,+7) | |
| Lay direction of outermost layer | Right hand | ||
| Approx.Overall diameter | mm | 13.5 | |
| Cross-sectional area | mm2 | 111.3 | |
| Approx. mass(without grease) | Kg/km | 304 | |
| Approx. mass(with grease) | Kg/km | 307 | |
| Minimum breaking load | kN | 24.3 | |
| Maximum DC resistance at 20ºC 20ºC | Ω/km | 0.266 |
PACKING DETAIL
Conductors shall be wound on a non-returnable fumigated drum or metal drum. The
required marking shall be printed with a weather-proof material on the outsides of drum
according to customer's requirement.
| Cable Type | Drum Length | Drum Dimensions & Weights | Material | |||||
| D | d | B | b | A | Net Weight | |||
| m | mm | mm | mm | mm | mm | kg | ||
| HYDROGEN CG 7/4.50 | 1500 | 1000 | 500 | 720 | 600 | 95 | 461 | Fumigated wooden drum |
| Note: 1 The value"D" don't contain the dimension of seal. 2 The approximate weight of drum(Φ1000) is 100 kilograms. | ||||||||
