WESPC Fuel Filter Assembly 2656F087 For for Perkins 1104C-44T Diesel Engines

Application

Fuel Filter Assembly 2656F087 is purpose-engineered for for Perkins 1104C-44T and 1104D-E44TA diesel engines. These engines are widely used in generator sets, agricultural tractors, and construction machinery. The assembly provides secure mounting and filtration for cartridge-type fuel filters, ensuring clean fuel delivery and protecting injection components from particulate contamination during extended operation.

Technical specifications

Thread M16 × 1.5 inlet and outlet ports, overall body height 125 mm. The unit supports spin-on or cartridge filters with integrated water separation. Designed for multi-stage filtration systems with primary and secondary elements. Compatible with fuel systems operating at pressures up to 5 bar. Includes drain port and sensor mounting provision.

Material & performance features

The housing is cast from corrosion-resistant aluminum alloy and finished with a protective coating for durability in harsh environments. Internal channels are precision-machined to ensure consistent fuel flow and pressure stability. The base supports vibration-resistant sealing and is suitable for high-temperature diesel applications.

Interchange part numbers

2656F087, 2656F087-P, 2656F087A; verified fitment for for Perkins 1100 series engines in industrial and power generation platforms
