160 Ton Maximum Pressure 5 Layers Hydraulic Hot Press Machine for Architectural Aluminum Honeycomb Panel Forming
Price:
Online/offline communication
MOQ:
1
Delivery Time:
25-30Work days
Brand:
Henrriet
Product Description
Multi-layer Hydraulic Hot Press for Architectural Aluminum Honeycomb Panel Forming
Product Overview
This five-tier downward-acting hot press uses a heavy-duty split frame construction, combined with stacked platens arranged in parallel and a built-in electrical control panel. Pressing force is provided by the hydraulic circuit, while a hot-oil circulation heating loop helps keep the temperature steady. Its space-saving configuration supports smooth operation in composite board manufacturing.
Key Features
- Superior Production Capacity: Multiple separate pressing chambers allow several groups of panels to be pressed within one cycle, reducing waiting time between batches and fitting continuous production line rhythms.
- Security Guarantee: Protective fencing, e-stop switches, pressure monitoring, and overloading safeguards ensure safer working conditions; industrial-grade seals minimize leakage risks.
- Application Areas: Ideal for laminate shaping of sandwich-type composite materials, joining skins to honeycomb cores, and hot pressing of composite door panels for construction and industrial applications.
- Maintenance & Upkeep: Modular configuration with divided sections for hydraulic, heating, and electrical components simplifies servicing, supported by inspection ports and separate media drainage.
Technical Specifications
| Parameter | Specification |
|---|---|
| Maximum Pressure | 160 Ton |
| System Pressure | 20 MPa |
| Work Platen Size | 4000×1500×50 mm |
| Maximum Platen Opening | 120 mm × 5 Layers |
| Maximum Temperature | 100°C (Adjustable) |
| Working Level | 5 Layers |
| Oil Cylinder Specification | 110mm×80mm × 8 pcs |
| Hydraulic Pump Power | 7.5 kW |
| Hot Oil Pump Power | 3 kW |
| Heating Pipe Power | 54 kW |
| Overall Dimensions | 3800×2000×2500 mm |
| Weight (Approx.) | 20000 kg |
Company Advantages
- Direct Manufacturer Pricing: Two in-house factories eliminate middlemen, providing better prices and faster delivery with full production control.
- Custom Engineering: 30+ senior engineers design machines tailored to your production needs, floor space, and budget requirements.
- Global Certification: CE & ISO 9001 certified machines meet international electrical, mechanical, and safety standards for worldwide operation.
- Proven Experience: 1000+ projects across 50+ countries with equipment engineered for long-term, heavy-duty factory use.
Service & Support
- Warranty: 1 year comprehensive coverage
- Packaging: Protective film with foam insulation
- 24-hour customer service hotline with 48-hour response for repair needs
- Free video training for operators with comprehensive process guidance manuals
- Lifetime technical support and software upgrade services
Product Image
5 Layer Down-stroke Hot Press
Company Profile
Manufacturing Facility
Production Equipment
Corporate Advantages
International Visitors
Manufacturing Process
Industry Exhibitions
Packaging & Logistics
Certificates & Honors
Frequently Asked Questions
Who are we?
Based in Guangdong, China since 2016, we serve Domestic Market (55%), Africa (20%), South Asia (9%), Central America (6%), Oceania (5%), South America (3%), and Eastern Asia (2%) with over 110 employees.
Why should you buy from us instead of other suppliers?
With over 20 years in wooden machinery industry, we operate two factories covering 20,000+ square meters with 130+ professional employees including 30+ engineers. We provide custom machine design, comprehensive installation, commissioning, and operator training for immediate production startup.
How do we guarantee quality?
Our quality process includes: customer requirement confirmation, engineer-designed machine drawings, on-site guidance for cutting/welding/assembly, full process functionality testing, and final pre-shipment inspection by engineers and project leaders.
What products can you buy from us?
We offer hydraulic cold presses, single-layer and multi-layer hot presses, glue spreading machines, automatic feeders, turnover machines, automatic palletizers, and custom non-standard automated production lines.
What services do we provide?
Delivery Terms: FOB, CFR, CIF, EXW, Express Delivery. Payment: USD, EUR, CNY via T/T, L/C, PayPal, Western Union, Cash. Languages: English, Chinese, Spanish, Japanese, Russian, Hindi.
