High Speed Liquid Silicone Pacifier Demoulding And Molding Machine Food Grade Silicone Equipment
Price:
USD17999-USD34999per set
MOQ:
1 SET
Delivery Time:
30 days
Brand:
Better
Product Description
High-Speed Liquid Silicone Pacifier Demoulding and Molding Machine Food-Grade Silicone Equipment
LSR Dosing Unit Features
- Over 20 years of experience in LSR technology
- Imported CNC machining for precise component processing
- Multiple motor options: hydraulic, hydraulic servo, or servo
- High injection precision: ≤0.01g
- Adjustable ratio (1:1 standard, servo motor adjustable)
- Feeding volume: 0-4000g/60s (varies by viscosity)
- Consistent color mixing: 0.3-4%
- Pneumatic system: R3/8", 6 bar
- Mix mold options: static, dynamic, or static+dynamic
- Working principle: plunger or gear pump
Applications
Suitable for infants and children products, automotive parts, medical devices, electronics, sports equipment, daily use items, electric power components, and more.
High-Precision LSR Dosing System
- All components processed with imported equipment for maximum accuracy
- Core parts imported from Europe/America for stability and longevity
- Easy-maintenance design with detachable displacement pump
- Long-life sealing elements
- Material shortage and over-pressure alarm safety systems
- Reproducible color adjustment capability
- Optimized coating through special material barrel design
- Material barrel emptying alarm
- Custom options available for special requirements
- Compliance with international and European standards
- Flexible barrel sizes (200L or 20L options)
- Durable hard metal ball valve and high-speed steel piston rod
- Coolable mixing section
- Colorant addition and metering device
- Continuous feeding pump operation
- Pressure gauge display for mixed materials
The system precisely meters two components in desired ratios to the injection unit via a specialized delivery system. Can be integrated with existing LSR equipment or provided as part of a complete turn-key solution.
Technical Specifications
| Parameter | Value |
|---|---|
| System Type | BETTER LSR Dosing System |
| Characteristics | A/B ratio 1:1 |
| Item No | Better 216 |
| Shot Volume | 0 - 1500g |
| Material Capacity | 20L / 200L |
| Ratio | 1:1 |
| Motor Source | Hydraulic |
| Dimensions | 1375 x 1030 x 2280 mm |
| Weight | 850KG |
| Mix Mode | Static Mixing |
| Work Style | Plunger Pump |
| Application | Universal |
