New Energy Vehicle Parts Battery Sealing Ring Injection Molding Machine LSR
Price:
USD42000-USD82000per set
MOQ:
1 SET
Delivery Time:
50 days
Brand:
Better
Product Description
Liquid Silicone Rubber New Energy Vehicle Parts Battery Sealing Ring Injection Molding Machine
S-guangyu provides integrated solutions including machinery, mold, and support services for manufacturing medical parts and new energy vehicle components.
Key Features
- Independent double-cylinder injection system ensures injection stability and allows for different glue types
- Independent direct pressure clamping unit accommodates various mold thicknesses
- Mechanical positioning device guarantees accurate positioning and mold protection
- Flexible independent system design enables single-mode production
- Comprehensive range of technical options available
Specifications: BETTER 1200SD-3RT Vertical LSR Injection Molding Machine
| Clamping Force | 120 tons |
| Size | 1290×560mm |
| Max Mold Size | 550×550mm |
| Min Mold Height | 120mm |
| Mold Stroke | 280mm |
| Max Daylight | 400mm |
| Ejector Force | 3 tons |
| Thimble Diameter | Φ25 |
| Ejector Distance (Product) | 300mm |
| Max Hydraulic Pressure | 140kg/cm² |
| Cooling Water | 1500-1800 liters/hr |
| Electrothermal | 4kW |
| Motor | 15kW |
| Dimension (L×W×H) | 2.28×2.6×3.12/3.86m |
| Weight | 7.4 tons |
System Highlights
Mould Clamping Device: Finite element analysis casting ensures strength. Movable plates and tail plates feature hinged lugs for enhanced rigidity.
Injection Device: Proprietary high-precision dosing machine ensures stable injection process with precise operation and intelligent control.
Control System: Full digital CAN control mode enables accurate pressure and flow control with easy operation and maintenance.
Manifold: Equipped with YUKEN solenoid valves for reliable sealing, stable operation, and long service life.
Main Die Cylinder: Forged steel construction provides exceptional stability.
Adjustable Ejector: Flexible design accommodates various mold characteristics.
PLC System: High-quality distribution box for reliable operation.
Operation Interface: User-friendly computer display reduces waiting time and simplifies operation.
LSR Process Features and Options
- Special LSR injection unit with dedicated barrel and screw featuring static seal
- Closed loop liquid barrel cooling system
- Pin-type shut-off nozzle (pneumatic or hydraulic actuation)
- LSR nozzle tip with static seal
- Optional spring-lock positive shut-off design for tip assembly
- Carriage decompression control
- Integrated mold temperature control system
- Insulated platens
- Precision LSR closed loop process software for volumetric control
- Mould vacuum system with pump, switch, interface and control software
- Mould sweep software and device interface
- Mould cold deck valve gate control system
- Pressure-regulated air blow system
- Pre-dosing assembly with temperature-controlled static mixer and purge valve
- Complete LSR material delivery system
