6 Layer Rigid Flex PCB with Immersion Gold Finish
Price:
USD0.1-1000
MOQ:
1pcs
Delivery Time:
5-8 working days
Brand:
ONESEINE
Product Description
ISO9001 HI TG Rogers Flex Circuit PCB Board Production For Electronics
Product Specifications
| Attribute | Value |
|---|---|
| Product Type | Rigid-flex PCB |
| Layer Count | 6 |
| Customization | Customized |
| Finish | Immersion Gold |
| Manufacturing Location | Shenzhen |
| PCB Conveying Speed | 0-17.5M/Min |
| Lead Time | 2-15 Days |
| Order Quantity | 1-500,000 |
Product Overview
Customized 6 Layer Rigid Flex Circuit Design From Shenzhen Manufacturer
Quick Details
- Number of layers: 6
- Board thickness: 1.2mm
- Brand: ONESEINE
- Sample order: Acceptable
- Application: Electronics products
- Surface finish: Immersion gold
- Item: rigid-flex PCB boards
Our Services
We provide comprehensive electronics manufacturing services including:
- PCB Production (FR-4, HI-TG, Aluminum, FPC, Rogers, CEM-1)
- FPC/PCB Copy Service
- PCB Assembly Service (SMT, BGA, DIP)
- IC programming with HEX file
- PCBA Housing assembly service
- PCBA Functional Testing
- PCBA Copy Service
- Electronic Components Purchasing
- PCB SMT Stencil (Laser cut & Etching)
- Cable assembly
Why Choose Us?
- Professional engineering team for design review and production preparation
- Extensive PCB manufacturing experience ensuring high quality and competitive pricing
- Comprehensive after-sales support with professional solutions
- Responsive customer service with constant follow-up
- Certified production standards (ISO, UL, ROHS)
Process Capabilities
| Capability | Specification |
|---|---|
| Layers | Single Sided, 2 to 18 Layer |
| Board material type | FR4, CEM-1, CEM-3, ceramic substrate, aluminum based, high-Tg, Rogers |
| Compound material lamination | 4 to 6 layers |
| Maximum dimension | 610 x 1,100mm |
| Dimension tolerance | ±0.13mm |
| Board thickness coverage | 0.2 to 6.00mm |
| Board thickness tolerance | ±10% |
| DK thickness | 0.076 to 6.00mm |
| Minimum line width | 0.10mm |
| Minimum line space | 0.10mm |
| Outer layer copper thickness | 8.75 to 175µm |
| Inner layer copper thickness | 17.5 to 175µm |
| Drilling hole diameter (mechanical drill) | 0.25 to 6.00mm |
| Finished hole diameter (mechanical drill) | 0.20 to 6.00mm |
| Hole diameter tolerance (mechanical drill) | 0.05mm |
| Hole position tolerance (mechanical drill) | 0.075mm |
| Laser drill hole size | 0.10mm |
| Board thickness and hole diameter ratio | 10:1 |
| Solder mask type | Green, Yellow, Black, Purple, Blue, White, Red |
| Minimum solder mask | Ø0.10mm |
| Minimum size of solder mask separation ring | 0.05mm |
| Solder mask oil plug hole diameter | 0.25 to 0.60mm |
| Impedance control tolerance | ±10% |
| Surface finish | HASL, ENIG, immersion silver, gold plating, immersion tin, gold finger |
Rigid-flex PCB Technology
A rigid-flex PCB combines rigid and flexible materials in its construction, offering the advantages of both technologies. This hybrid solution is ideal for applications with space constraints, complex geometries, and demanding reliability requirements.
The board consists of multiple layers of rigid FR4 materials and flexible polyimide sections. Rigid portions provide structural support for components, while flexible areas allow the board to bend or fold as needed.
Key Benefits
- Space efficiency: Eliminates connectors and cables for significant space savings
- Enhanced reliability: Fewer interconnects and solder joints reduce failure points while improving vibration and thermal stress resistance
- Superior signal integrity: Optimized routing minimizes signal loss and improves performance
- Design flexibility: Accommodates complex and irregular shapes for innovative product designs
