3 Layer Rigid Flex PCB Board Customized 2OZ 3OZ Copper
Price:
USD0.1-1000
MOQ:
1pcs
Delivery Time:
5-8 working days
Brand:
ONESEINE
Product Description
ONESEINE 3 Layer Rigid Flex PCB Board Prototype Circuit 2OZ 3OZ
Product Specifications
| Attribute | Value |
|---|---|
| Product Type | Rigid-flex PCB |
| Layer Count | 3 |
| Customization | Customized |
| Manufacturing Location | Shenzhen |
| Profiling Punching | Routing, V-CUT, Beveling |
| Soldermask | Yellow Coverlay, Green soldermask |
| Copper Thickness | 1oz, 1/2OZ 1OZ 2OZ 3OZ, 0.5-3.0 oz, 1 Oz |
| Color | Green |
Product Description
3 Layer Circuit Image Acquisition Analysis Transmission Lens Rigid Flex PCB Board
Quick Details
- Number of layers: 3
- Board thickness: 1.2mm
- Brand: ONESEINE
- Sample order: Acceptable
- Application: Electronics products
- Surface finish: Immersion gold
- Item: rigid-flex PCB boards
Our Services
We provide comprehensive electronics manufacturing services with the highest quality standards.
- PCB Production (FR-4, HI-TG, Aluminum, FPC, Rogers, CEM-1)
- FPC/PCB Copy Service
- PCB Assembly Service (SMT, BGA, DIP)
- IC programming with HEX file
- PCBA Housing assembly service
- PCBA Final Functional Testing
- PCBA Copy Service
- Electronic Components Purchasing & BOM List Services
- PCB SMT Stencil (Laser cut & Etching)
- Cable assembly
Why Choose Us?
- Professional engineering team for design verification
- Extensive PCB production experience for high quality at competitive prices
- Comprehensive after-sales support
- Responsive customer service with constant follow-up
- Quality certified (ISO, UL, ROHS)
Process Capability
| Capability | Specification |
|---|---|
| Layers | Single Sided, 2 to 18 Layer |
| Board material type | FR4, CEM-1, CEM-3, ceramic substrate board, aluminum based board, high-Tg, Rogers |
| Maximum dimension | 610 x 1,100mm |
| Board thickness coverage | 0.2 to 6.00mm |
| Minimum line width/space | 0.10mm |
| Copper thickness (outer/inner) | 8.75 to 175µm / 17.5 to 175µm |
| Drilling capabilities | 0.25 to 6.00mm (mechanical), 0.10mm (laser) |
| Solder mask options | Green, Yellow, Black, Purple, Blue, White, Red |
Rigid-flex PCB Introduction
A rigid-flex PCB combines both rigid and flexible materials in its construction, offering the advantages of both types of circuit boards. This hybrid solution is ideal for applications with space constraints, complex geometries, and demanding reliability requirements.
Key benefits include:
- Space efficiency: Eliminates connectors and cables for compact designs
- Enhanced reliability: Fewer interconnects and better resistance to vibration/thermal stress
- Superior signal integrity: Optimized routing reduces signal loss
- Design flexibility: Conforms to complex and irregular shapes
