Professional Transparent Solar Tempered Glass PV Glass Clear Tempered Glass For Solar Panels
Professional Transparent Solar Tempered Glass PV Glass Clear Tempered Glass For Solar Panels
Photovoltaic (PV) tempered glass, also referred to as low-iron tempered solar glass, is a high-performance, safety-enhanced glass specifically engineered for using on solar energy. It is manufactured by advanced continuous roll-impression technology and precision tempering processes, this glass integrates exceptional optical properties, mechanical strength, and processability, making it an indispensable core material for photovoltaic panel. it has high light transmittance of 93.8%, it also can used as the greenhouse of plants and vegetables material, it also can be used on construction of curtain wall
Specification
| Thickness | 2mm,2.5mm,3.2mm,4mm |
| Producing Size | 100*100mm(Min size ),2400*2600mm(Max size) |
| light transmittance | without coating more than 91.7%, with AR coating more than 93.8% |
| Colors | Clear and ultra clear |
| Package | Safety seaworthy wooden and plywood packing with paper interleaved |
| Applications | solar panel and solar water heater greenhouse curtain wall of construction |
| Types |
1.Solar patterned glass(tempered or non-tempered)
2.Solar float glass(temoered or non-tempered) |
Features:
- Superior Optical Performance: With ultra-high solar transmittance and low light reflectance, effectively maximizing solar energy capture and conversion efficiency. AR (Anti-Reflective) coating can be applied to further reduce reflection and optimize energy yield.
- Exceptional Mechanical Strength: Undergoes full tempering treatment (heating to ~621°C followed by rapid quenching), achieving four times the strength of standard annealed glass. It delivers reliable resistance against hail impact, mechanical loads, and thermal stress cracking, ensuring long-term stable operation in harsh outdoor environments.
- Enhanced Safety & Durability: Breaks into small, granular, non-sharp fragments when shattered, significantly reducing the risk of injury. Its low iron content minimizes light absorption, while excellent weather resistance ensures resistance to UV radiation, humidity, and corrosion, extending the service life of PV modules.
- Excellent Processability: Easy to cut, coat, and laminate, adapting to diverse post-processing requirements of crystalline silicon (mono/poly/HJT), thin-film (CdTe/CIGS/a-Si) PV modules, and other solar products.
Application:
Designed for seamless integration with various photovoltaic systems, this glass combines optical efficiency, safety, and durability to meet the demands of residential, commercial, and utility-scale solar projects. Its diversified pattern options and customizable configurations (e.g., thickness, coating) provide flexible solutions for BIPV (Building-Integrated Photovoltaics), solar farms, portable solar devices, and PV-T hybrid systems.
Glass pictures:
