ACS580-01-169A-4 3ABD00045438-D ABB LV AC General Purpose Wall-mounted Drive
ACS580-01-169A-4 3ABD00045438-D ABB LV AC General Purpose Wall-mounted Drive
The ACS580-01-169A-4 is a wall-mounted standard drive product in ABB Group's ACS580 series of general-purpose frequency converters, designed specifically for speed control of three-phase AC asynchronous and synchronous motors in industrial applications. This model has a rated output current of 169A, is compatible with 400V voltage levels, and covers a power range typical of 75kW to 90kW applications. It perfectly balances high-performance vector control technology with plug-and-play convenience, making it an ideal drive choice for general mechanical loads such as fans, pumps, compressors, and conveyors. As a core member of ABB's All-compatible drive family, the ACS580-01-169A-4 sets an industry benchmark in hardware compatibility, software functionality completeness, and lifecycle cost optimization.
Technical Specifications
| Model Number | ACS580-01-169A-4 |
| Ordering Code | 3ABD00045438-D |
| Brand | ABB |
| Series | ACS580-01 (Wall-Mounted) |
| Motor Power | 75 kW (100 HP) |
| Supply Voltage | 380–480 V AC, 3-phase, ±10% |
| Output Current | 169 A (continuous) |
| Overload Capacity | 150% for 60 sec (normal duty) |
| Control Modes | Scalar, Sensorless Vector (DTC) |
| EMC Filter | Integrated C2 class (for non-industrial environments) |
| Protection Rating | IP21 (standard), upgradable to IP55 |
| Communication | RS485 (Modbus RTU), optional Ethernet/IP, PROFINET, BACnet/IP |
| Safety Function | STO (Safe Torque Off) – SIL 3 / PL e |
| Operating Temperature | -10°C to +40°C (derating above 40°C) |
| Certifications | UL, CE, EAC, KC, RCM, CCC, RoHS, REACH |
