FS450R12KE3AGDR-71C ABB S CODE 68569354 IGBT Module ACS800 Series High-Power Drive Module with AGDR-71C Driver Board
Price:
$240
MOQ:
1 pc
Delivery Time:
3-5 days
Brand:
ABB
Product Description
FS450R12KE3AGDR-71C ABB S CODE 68569354 IGBT Module ACS800 Series High-Power Drive Module with AGDR-71C Driver Board
The ABB FS450R12KE3AGDR-71C S CODE 68569354 is a high-performance IGBT module kit designed for ABB ACS800 series AC drives, combining the FS450R12KE3 IGBT power module with the AGDR-71C driver board for optimal power conversion and control in industrial applications. This integrated solution provides reliable and efficient power switching for medium to high-power drive systems.
Engineered with ABB's proven reliability, the FS450R12KE3AGDR-71C features robust construction with industrial-grade components designed for extended service life in demanding industrial environments. The IGBT module delivers high power density with 450A rated current and 1200V blocking voltage, ensuring efficient operation in heavy-duty applications such as pumps, fans, compressors, and industrial machinery.
The 68569354 kit includes the AGDR-71C driver board, which provides isolated gate drive signals, protection circuits, and communication interface for seamless integration with the drive controller. The complete assembly ensures plug-and-play compatibility with ACS800 series drives, minimizing installation time and ensuring maximum operational efficiency in critical industrial processes.
Product Specifications: ABB FS450R12KE3AGDR-71C
| Parameter | Specification |
|---|---|
| Brand | ABB |
| Model Number | FS450R12KE3AGDR-71C |
| Part Number | 68569354 |
| Type | IGBT Module with Driver Board Kit |
| Compatible Series | ACS800 AC Drives |
| Function | Power conversion and drive control |
| IGBT Module Type | FS450R12KE3 |
| Driver Board Type | AGDR-71C |
Product Images
Related Products
| FS300R12KE3AGDR-61C | FS225R12KE3AGDR-71C |
| FS600R12KE3AGDR-81C | FS450R17KE3AGDR-71C |
| FS300R17KE3AGDR-61C | FS225R17KE3AGDR-71C |
| FS600R17KE3AGDR-81C | FS450R12KE4AGDR-71C |
| FS300R12KE4AGDR-61C | FS225R12KE4AGDR-71C |
| FS600R12KE4AGDR-81C | FS450R17KE4AGDR-71C |
| FS300R17KE4AGDR-61C | FS225R17KE4AGDR-71C |
| FS600R17KE4AGDR-81C | FS450R12KT3AGDR-71C |
| FS300R12KT3AGDR-61C | FS225R12KT3AGDR-71C |
| FS600R12KT3AGDR-81C | FS450R17KT3AGDR-71C |
FAQ
Q1: FS450R12KE3AGDR-71C still available?
A: Yes, this is an active ABB spare part.
A: Yes, this is an active ABB spare part.
Q2: Compatible drives?
A: ACS800 series AC drives.
A: ACS800 series AC drives.
Q3: Rated current and voltage?
A: 450A current, 1200V blocking voltage.
A: 450A current, 1200V blocking voltage.
