CTS Solar Battery Storage System 20kwh 30kwh 48v With 5kw Hybrid Inverter

Price Negotiable

Price: 1800-2200USD

MOQ: 2 unit

Delivery Time: 15 working days

Brand: CTS

Product Description

CTS Solar Battery Storage System All In One 20kwh 30kwh 48v Lifepo4 Battery With 5kw Hybrid Inverter
★ Module design with flexiable expansion to 30kwh★ A+++ LFP cell and reliable BMS design ★ Pulley and rail design ensures easy and quick in stallation of the system ★ Low-voltage batteries and inverters provide cost-effective storage systems★ Build in MPPT with 99% efficient ★ Operating temperature ranges from -10C to 55C

			System specification

			Model

			LS51100-FP5

			LS51200-FP5

			LS51300-FP5

			LS51400-FP5

			LS51500-FP5

			LS51600-FP5

			Inverter parameter

			PV input power

			4000W

			PV max charge current

			80A

			Max PV Voltage

			145VDC

			MPPT voltage range

			64~130VDC

			Number of Mppt

			1

			EPS output power

			5000W

			EPS output voltage

			230VAC

			EPS output current

			21.7A

			EPS output frequency

			50/60HZ

			EPS Transfer Time

			≤ 20ms

			Waveform

			Pure Sine Wave

			AC charge current

			60A

			Battery parameter

			Battery Type

			LiFePo4

			LiFePo4

			LiFePo4

			LiFePo4

			LiFePo4

			LiFePo4

			Rated voltage

			51.2

			51.2

			51.2

			51.2

			51.2

			51.2

			Rated capacity

			100AH

			200AH

			300AH

			400AH

			500AH

			600AH

			Energy(25°C, 0.5C)

			5.12kwh

			10.24kwh

			15.36kwh

			20.48kwh

			25.6kwh

			30.72kwh

			Safety standard

			IEC62619, UN38.3, MSDS

			System parameter

			Display

			7 inch touch LCD

			Operating temperature

			-10°C~60°C

			Humidity

			15%~85%(No condensation)

			Size(W*D*H)

			640*400*1068mm

			640*400*1336mm

			640*400*1604mm

			640*400*1872mm

			640*400*2140mm

			640*400*2408mm

			weight

			88kg

			136kg

			184kg

			232kg

			280kg

			328kg

★Can be stackedMobile home enrgy storage battery, A single battery is 5KH, which can be satcked up to 30KH,Effectively respond tosudden power outages and planned power restrictions
Data Monitoring Voltage, Current, Tmperature, etc. Safety Protection Overcharge, Overdischarge, Overcurrent, Overtemperature, Online alarm, etc. Data Interaction CAN, RS485,

Smart Switch
Optional Off-grid/on-grid inverter Integrateddesign,Off-grid operation supporting emergencypower supply,switchable at any time, multiple inverter modes,3/4/5KW
★ Intelligent Battery Management SystemSmart 7 Inch Touch screen display the parameters of theequipment in real time,and the runningstatus is clear at a glance.

CTS Custom High-Voltage LiFePO4 Battery Solutions (300V - 800V | 40kWh - 250kWh+) for Heavy-Duty EVs & Commercial Applications

IP67 Waterproof 6.6kW 11kW 22kW On Board Charger OBC Liquid Cooled For Electric Vehicle Marine Boat With CAN Bus

CTS 51.2V 314Ah Marine LiFePO4 Battery Solution for Yacht /Catamaran

Golf Cart 48V 51.2V 105AH Lithium ion Battery LIFEPO4 - Fits Club Car Ez Go Yamaha & Universal Golf Cart Models

12V 100Ah 200AH 300AH 400AH Lifepo4 Battery for Solar Energy Storage Systems Best Lifepo4 Battery With High Performance

Grade A LG MH1 18650 3.7V 3200mAh Lithium Ion Battery

CTS 800V 600V 100kWh LiFePO4 High Voltage EV Battery Pack for Electric Tractor & Logistics Vehicle OEM Solution

CTS 24V 48V Custom LiFePO4 Battery Pack For AGV Industrial Robot Material Handling

CTS 48V 105Ah 5.04kWh Bluetooth BMS golf cart battery For LSV OEM ODM With 5 years warranty

All-in-One 240kW Solar & 522kWh BESS with Integrated 250kW PCS

36V 48V 60V 72V Lithium Golf Cart Battery Pack with Bluetooth BMS APP Rechargeable Li-ion Battery for AGV Forklift

Grade A 3.7 Volt LG IMR 21700 Lithium Ion Battery 5000 mAh
