Special High-Gloss FRP Sheet for Refrigerated Trucks 90-96° Mirror Finish 3500mm Extra-Wide
Introduction
FRP panels are becoming a pivotal choice for industrial advancement due to their revolutionary material properties. Their core value lies in unifying lightweight design with high strength, while offering exceptional corrosion resistance and comprehensive safety. Additionally, they integrate benefits such as impact resistance, aging resistance, thermal and acoustic insulation, ease of molding, and low maintenance costs. Whether facing the stringent demands for energy efficiency and durability in transportation, the complex needs of architectural decoration and high-end manufacturing, or the personalized requirements of home renovation, environmental projects, and specialized equipment, FRP panels deliver integrated solutions that balance function and aesthetics. Leveraging their stable performance and flexible adaptability, they continuously drive product iteration and innovation across industries.
|
![]()
|
![]()
![]()
Packaging & Shipping
To address product damage from violent shaking and collisions during long-distance transportation, we offer two protective solutions:
- Standard protection: Securing products with iron frames, wooden pallets and other accessories to guarantee basic transportation safety.
- Customized protection: Delivering tailored packaging based on your specific requirements, with 30% enhanced performance compared to the standard solution (e.g., specialized shock-absorbing materials, custom-fitted frames).
Customization Services
- Size customization: Thickness and length adjustable on demand, with a maximum width of 3500mm.
- Color customization: Matching with Pantone color cards available.
- Function upgrade: Flame retardant, antibacterial, and antistatic properties can be added.
- Free samples: A4-sized samples provided for testing.
Order Information
- Minimum Order Quantity: 200㎡ for standard products, 500㎡ for customized products.
- Delivery Time: 7-10 work days for standard products, 10-15 work days for customized products.
- Payment Methods: T/T Telegraphic Transfer, L/C Letter of Credit, Western Union.
- Technical Support: Professional engineers offer pre-sales solution design and after-sales installation guidance.
FRP Flat Sheet Overview
- Surface
High-gloss
Matt
Gel-Coat
Non Gel-coat
- Color
Customized
|
- Fiberglass
Fiberglass Felt
Woven Roving
Fiberglass Felt& Woven Roving
- Thickness
0.8-10mm
- Max. Width
3500mm
- Length
60/100/120m & Customized
|
- RV-specific Sheet
- Suitable for curved application
- High-impact resistant panels
- Paint-ready panels
- Fire-retardant panels
FRP sheet performance data
No.
|
Test ltems |
Unit |
39140Series |
39380Series |
38501Series |
38351Series |
Test Standard |
| 1 |
Density |
g/m3 |
1.35-1.5 |
1.35-1.55 |
1.4-1.6 |
1.5-1.8 |
|
| 2 |
Tensile Strenght |
Mpа |
60-90 |
80-100 |
110-140 |
120-150 |
GBT/T1447 |
| 3 |
Flexural Strength |
Mpa |
80-120 |
110-150 |
160-210 |
180-250 |
GBT/T1449 |
| 4 |
Flexural Modulus |
Mpa |
4.1x10³-5.8x10³ |
4.6x10³-6.2x10³ |
5.5x10³-8.6x10³ |
5.3x10³-8.05x10³ |
GBT/T1449 |
| 5 |
Impact Toughness |
KJ/m2 |
35-55 |
40-60 |
60-80 |
60-90 |
GBT/T1451 |
| 6 |
Water Absorbtion |
% |
0.15-0.16 |
0.15-0.16 |
0.15-0.16 |
0.15-0.16 |
GBT/T1462 |
| 7 |
Oxygen Index |
% |
22-32 |
22-32 |
22-32 |
22-38 |
GBT/T8924 |
| 8 |
Barcol hardness |
Mg |
30-40 |
34-45 |
35-50 |
40-50 |
GBT/T2576 |
