LOP-200-48 Switching Power Supply 201.6W 48V 4.2A Medical 2X4 Low Profile
Price:
Negotiable
MOQ:
36
Delivery Time:
2-4days
Brand:
New and Original
Product Description
LOP-200-48 Switching Power Supplies 201.6W 48V 4.2A Medical 2X4 Low Profile
Product Overview
High-efficiency medical-grade switching power supply with compact dimensions and robust performance characteristics.
Key Specifications
| Category | Switching Power Supplies |
|---|---|
| Output Voltage | 48 VDC |
| Output Current | 4.2 A |
| Output Power | 200 W |
| Input Voltage | 80 VAC to 264 VAC, 113 VDC to 370 VDC |
| Efficiency | 94% |
| Dimensions | 101.6 mm * 50.8 mm * 25.4 mm (4" * 2" * 1") |
Technical Details
Industry: Medical
Mounting Style: Chassis
Approvals: EN60335-1, EN61588, IEC, UL
Isolation Voltage: 4 kVAC
Operating Temperature: -40°C to +80°C
Power - Convection: 144 W
Power - Forced Air: 201.6 W
Brand: MEAN WELL
Series: LOP-200
Product Images
Additional Information
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Factory Pack Quantity: 36
Unit Weight: 7.41 oz (210 g)
RoHS: Compliant
