High Efficiency Bonding 150*150mm FPC FFC to Pcb White Heat Pluse Soldering with 0.2mm Pin Distance

Hot-Bar Bonding - Advanced Integrated Technologies,CW-2A2P Discription:

Hot bar soldering is extremely effective in bonding components and parts that are dissimilar and difficult to unite. Several examples are listed above, but there are many other soldering situations that call hot bar reflow soldering system. This technology, also known as pulse bonding, differs from traditional soldering since the reflow process uses thermode technology, which is based on rapid reflow by pulse heating. This procedure allows materials with low temperature resistance to be soldered at high lead-free temperatures without damage to the flex. It selectively solders parts by heating them to a temperature that's high enough to cause their adhesive or solder to melt and then re-solidify to form a permanent bond.

Hot-Bar Bonding - Advanced Integrated Technologies,CW-2A2P



Hot-Bar Bonding - Advanced Integrated Technologies,CW-2A2P

1. Customized based on the connector, 2. Double jig welding, 3. Double- desk working mode, 4. Can achieve ultra-fine pitch welding, 5.Applicable to welding the cable and connection of communicating machine.	NO.	Subject	Parameters
	1	Machine size	L850×W650×H1320mm
	2	Working size	Max150x150mm
	3	weight	98KG
	4	working air pressure	0.5~0.80 Mpa
	5	power supply	AC220V±10％50HZ.2000W
	6	Lifting temperature setting	Five section
	7	work environment	10~60℃,40％~95％
	8	Welding pressure	4~50N
	9	Welding pressure error	±1N
	10	Temperature setting	RT∽500℃,±2℃
	11	Heating rate	250℃/s
	12	Welding time	1-99.9S
	13	welding precision	Pitch 0.2mm
	14	Welding head size(Mmetal)	Max 50*3mm
	15	Welding head size(T metal)	Max 100*3mm
	16	Welding head flatness	±0.02mm
	17	Pin distance range	＞0.2mm
	18	Alignment mode	Artificial alignment
	19	Positioning fixture	2
	20	Way of discharge	Artificial pick and place
	21	Start mode	Pressed by hands
	22	Heatingmethod	Pulse heating, the rise timeis 1 ~ 2S
	23	Work Stage	Left and right automatic push and pull
	24	Platform control	Precision motor control, error <0.02mm


Hot Bar ProductsSystems for Hot Bar Reflow Soldering,CW-2A2P Function Module:


【Double welding head design】 Applicable to double-sided welding products   【Left and right platform design】 In the production, It weld with left and right cycle, saving time and improving efficiency 【The upper and lower welding heads are driven by the motor】 Up and down position is precise, the same accuracy when it repeats   【The left and right platform is driven by motor】 Left and right position is precise, the same accuracy when it repeats   【Touch screen programming】 Easy to understand and program, we can enter data location directly


Hot Bar ProductsSystems for Hot Bar Reflow Soldering,CW-2A2P Related Products Catalogue :


Desktop terminal welding machineCWPP-5A	Double-sided welding automatic tin feed machine CWPP-D5A	Terminal testing and shell filling machine (terminal welding supporting equipment)


Soldering Fpc Ffc Hsc to Pcb Heat Welding with Hot Bar Bonding Equipment CE Certification:
