GB 50068 Roof Steel Structure 50 Meters - 150 Meters Metal Roof Trusses
Price:
8000 yuan per ton
MOQ:
10 tons
Delivery Time:
After confirming the drawings, the shipment will be made within 20 days .
Brand:
Shandong Xinghua Steel Structure
Product Description
Q355B High-Strength Steel Roof for Airport High-Speed Rail Station
prodnct deecrlption
Q355B high-strength steel space grid roof structure – engineered for large-span airport and modern transportation hubs .The structure achieves maximum spans up to 150 meters, creating expansive column-free spaces. Streamlined aerodynamic design reduces wind load impact by 30%. Intelligent drainage systems effectively handle heavy rainfall conditions in Southeast Asia, while natural lighting design reduces energy consumption by 42%. BIM technology ensures precise installation of complex structural nodes throughout the construction process.
Technical Specifications
Parameter Category |
Detailed Specifications |
International Standard |
Main Material |
Q355B high-strength steel |
GB/T 1591, ASTM A913, EN 10025 |
Structural Form |
Space grid structure, beam string structure, cable membrane structure |
GB 50017, EN 1993, ASCE 19 |
Span Range |
50-150 meters (standard design), 150-300 meters (special design) |
GB 50009, EN 1991, ASCE 7 |
Roof Material |
Aluminum magnesium manganese alloy sheet, ETFE film material, photovoltaic integrated sheet |
ASTM B209, EN 485, ISO 9227 |
Design Life |
≥ 52 years (important public building standards) |
GB 50068, ISO 13822 |
Key Advantages
-
Q355B ultra-high-strength steel enables over 150-meter large-span column-free spaces
-
Streamlined aerodynamic design reduces wind load by 30%, enhancing structural safety
-
Natural lighting design reduces energy consumption by 42%, meeting green building standards
-
BIM technology ensures precise implementation throughout complex project execution
Applications
-
International airport terminals and waiting halls
-
High-speed rail stations and rail transit hubs
-
Urban rail transit stations and underground spaces
-
Long-distance bus stations and transportation transfer centers
