RUIDA RDC6445G-MOD5 Standalone Laser Cutting Engraving Machine Controller
Price:
Negotiable - Inquire Within
MOQ:
50
Delivery Time:
5-8 work days
Brand:
RUIDA
Product Description
RUIDA RDC6445G-MOD5 Standalone Laser Cutting And Engraving Machine Controller
The RDC6445G-MOD5 system based on the MODBUS RTU communication protocol with open-source HMI, providing the source code of HMI for customers to customize operation pages based on the configured development environment. Compatible with most touch screens based on this protocol in the market.
Product Features
- Adopt HMI open-source system for quick customization of operation pages
- Based on MODBUS RTU communication protocol for broad touch screen compatibility
- Supports 4 motion axes, two laser interfaces and multi-channel general IO input/output
- Single/double laser head processing with synchronous operation and ultra-wide segmentation cutting
- Works with RDWorksV8 software including plug-in support and virtual printing
- Ideal for non-metal cutting applications including leather, fabric, signs, crafts, toys and 3C products
Software RDworks V8 (Free)
Supports PLT, DXF, AI, DST and other file formats import with display and edit functions. Includes image file import and processing capabilities.
Technical Specifications
| Parameter | RDC6445G-MOD5 |
|---|---|
| Laser source | CO2 glass tube, CO2 RF tube and UV lasers |
| Axis | 4 |
| Laser channel | 2 |
| Double heads synchronous | Supported |
| Communication | Ethernet, USB and WIFI (optional) |
| Panel | 5˝ touch screen based on MODBUS protocol with customizable interface |
| Laser cutting | Single beam |
| Feeding | U axis feeding, Y/U axes synchronous feeding, sheet feeding, large format segmentation |
| Encryption | Supported |
| Onboard clock | Supported (system time adjustable) |
| Firmware | Remote upgrade support for mainboard and panel program |
| Rotary | Y or U axis rotation mode optional |
| Engraving | Plane, slope and gray engraving |
| Processing | Resume after power failure supported |
| Software | RDWorksV8, RDPlug, virtual printing and RDImage |
| Language | Simplified Chinese, English |
| Size | Panel: 81×143.5×16.6mm Mainboard: 180×116.6×33.1mm |
| Accessories | Wireless handle, RD-APP and RD-WIFI |
Note: Virtual printing only supports Windows 10.
