RUIDA RDC6442S CO2 Laser Controller Non Metal Cutting Machine CO2 Control Panel
Price:
Negotiable - Inquire Within
MOQ:
50
Delivery Time:
5-8 work days
Brand:
RUIDA
Product Description
RUIDA RDC6442S CO2 Laser Controller for Non-Metal Cutting Machines
The RDC6442S system, based on RDC6442G, features a 3.5-inch color screen for enhanced user experience and advanced functionality. This controller delivers comprehensive motion control with onboard file storage and versatile U flash disk support. With multi-channel IO control and both Ethernet/USB connectivity, it offers exceptional flexibility for device integration.
Key Features:
- Dual communication options: USB and Ethernet with U flash disk support
- Four motion axes with extensive laser interfaces
- Independent color operation panel with push-button controls
- Compatible with RDWorksV8 software including plug-in support and virtual printing
- Wide range of optional external accessories
- Optimized for non-metal materials: leather, fabric, signage, crafts, toys, and 3C applications
RDWorks V8 Software (Free)
Supports PLT, DXF, AI, DST and other file formats with import, display and edit functions. Includes image file processing capabilities.
Technical Specifications
| Parameter | RDC6442S |
|---|---|
| Laser source | CO2 glass tube, CO2 RF tube and UV lasers |
| Axis | 4 |
| Laser channel | 2 |
| Double heads synchronous | Supported |
| Communication | Ethernet, USB and WIFI (optional) |
| Panel | 3.5" color screen + keys |
| Feeding | U axis feeding, sheet feeding/large format segmentation feeding |
| Encryption | Supported |
| Firmware | Remote upgrade supported |
| Rotary | Y or U axis rotation mode optional |
| Engraving | Plane, slope and gray engraving |
| Processing | Resume after power failure supported |
| Software | RDWorksV8, RDPlug, virtual printing and RDImage |
| Language | 12 languages supported including English, Chinese, Spanish, etc. |
| Size | Panel: 170×120×30.5mm Mainboard: 180×116.6×33.1mm |
| Accessories | Wireless handle, RD-APP and RD-WIFI |
Note: Virtual printing only supports Windows 10.
Advantages of RDC6442S Controller
- Intuitive Operation: 3.5-inch color screen for user-friendly control
- Advanced Capabilities: Handles complex laser tasks with precision
- Easy Integration: Multi-channel IO control for seamless equipment setup
- Flexible Storage: Onboard file storage for autonomous operation
- Reliable Connectivity: Ethernet and USB communication for efficient data transfer
