RUIDA RDC6442S Double Heads CO2 Laser Controller With Ethernet USB WIFI Connectivity
Price:
Negotiable - Inquire Within
MOQ:
50
Delivery Time:
5-8 work days
Brand:
RUIDA
Product Description
RDC6442S Double Heads CO2 Laser Controller With Free RDworks V8 Software And Ethernet/USB Connectivity
The RDC6442S system, a step up from the RDC6442G, features a 3.5-inch color display for enhanced user interaction and a broader range of functionalities. This advanced controller offers onboard file storage and a flexible U flash disk driver, alongside comprehensive motion control.
Key Functions and Capacities:
- Support USB and Ethernet communication and U flash disk
- Four motion axes and rich laser interfaces
- Independent color operation panel with push-button operation
- Works with independent application software RDWorksV8, supporting plug-in software and virtual printing
- Rich external auxiliary accessories are optional
- Focus on non-metal cutting applications including leather, fabric, signage, craft gifts, toys, and 3C products
Software RDworks V8 (Free)
Supports PLT, DXF, AI, DST and other file formats import, display and edit functions. Includes image file import and processing capabilities.
Technical Parameters:
| Parameters | RDC6442S |
|---|---|
| Laser source | CO2 glass tube, CO2 RF tube and UV lasers |
| Axis | 4 |
| Laser channel | 2 |
| Double heads synchronous | Support |
| Communication | Ethernet, USB and WIFI (optional) |
| Panel | 3.5" color screen + keys |
| Feeding | U axis feeding, sheet feeding/large format segmentation feeding |
| Encryption | Support |
| Firmware | Support the remote upgrade of mainboard |
| Rotary | Y or U axis rotation mode is optional |
| Engraving | Plane engraving, slope engraving and gray engraving |
| Processing | Support resume processing after power failure |
| Software | RDWorksV8, plug-in software RDPlug, virtual printing and RDImage |
| Language | 13 languages including English, Chinese, Spanish, French, German, etc. |
| Size | Panel: 170×120×30.5mm Mainboard: 180×116.6×33.1mm |
| Accessories | Wireless handle, RD-APP and RD-WIFI |
Note: Virtual printing only supports Win10.
Our Advantages:
- Upgraded Display: 3.5-inch color display for intuitive operation
- Advanced Motion Control: Sophisticated control for precise laser operations
- Onboard Storage: Convenient file storage for efficient task management
- Versatile Compatibility: Multi-channel IO control for wide device compatibility
- Flexible Connectivity: Ethernet and USB interfaces for seamless PC communication
- Feature-Rich: Comprehensive feature set for diverse laser processing needs
