CO2 CNC Laser Controller RDC7132G RUIDA Control Panel For Laser Engraving Cutting Machine
Price:
Negotiable - Inquire Within
MOQ:
50
Delivery Time:
5-8 work days
Brand:
RUIDA
Product Description
RUIDA RDC7132G CO2 Laser Controller CNC System
Laser Control Panel For CO2 Laser Engraving Cutting Machine ReplaceTrocen Leetro
Product Overview
The RDC7132G laser cutting and engraving control system by Ruida Technology features an integrated XY-axis stepper motor driver. For Z-axis control, it requires external step drives. The system includes USB2.0 for PC communication and supports file transfer via USB flash drives.
Key Features
- Autonomous Operation Capability
- Compatible with USB and Ethernet interfaces, plus U flash drives
- 3.5-inch color display with intuitive control buttons
- Combined drive and control functionality with integrated XY-axis stepper motor driver
- Multiple laser interfaces with optional external accessories
- Compatible with RDWorksV8 software, supports add-on software and virtual printing
Software Compatibility
RDworks V8 (Free) supports PLT, DXF, AI, DST and other file formats import, display and edit functions. Includes image file import and processing capabilities.
Technical Specifications
| Parameters | RDC7132G |
|---|---|
| Laser source | CO2 glass tube, CO2 RF tube and UV lasers |
| Axis | 3 |
| Laser channel | 1 |
| Drive mode | XY axis integrated two-phase stepping driver |
| Double heads synchronous | Not Support |
| Communication | Ethernet, USB and WIFI (optional) |
| Panel | 3.5" color character screen + keys |
| Feeding | Z axis feeding + sheet feeding |
| Encryption | Support |
| Onboard clock | Not support |
| Firmware | Support the remote upgrade of mainboard program |
| Rotary | Y axis rotation |
| Engraving | Plane engraving, slope engraving and gray engraving |
| Software | RDWorksV8, plug-in software RDPlug, virtual printing and RDImage |
| Language | 12 languages including English, Chinese, Spanish, German, etc. |
| Size | Panel: 108×148×26.1mm Mainboard: 180×116.5×33.1mm |
| Accessories | Wireless handle, RD-APP and RD-WIFI |
| Note | Virtual printing only supports Win10 |
Advantages
- Autonomous Operation: Standalone operation without continuous computer connection
- Versatile Connectivity: Multiple communication options including USB, Ethernet, and U flash drives
- User-Friendly Interface: 3.5-inch color screen with intuitive control keys
- Integrated Drive and Control: All-in-one system with XY-axis stepper motor drivers
- Flexible Laser Interfaces: Customizable with various laser interfaces and accessories
- Advanced Software Support: RDWorksV8 software with virtual printing capabilities
