Full Digital Desktop 8 Pin Wired Meeting Mic System for Conference Room with Speaker
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
HUAIN
Product Description
Products Description
Feature and function：
·Equipment 128 × 32 graphic LCD display, 6-inch super capacitive inductive panel.
·A multi-functional conference terminal integrating speech discussion, video tracking, voting, simultaneous interpretation and conference services.
·The system supports a variety of connection modes, such as one-line handle, T-head handle and ring handle.
·The system adopts 8-core DIN shielded cable or CAT5 cable.
·The unit is a passive equipment. The conference host provides 24V power supply, and 30 conference units can be connected in a single way.
·With the camera, the camera can be automatically tracked after preset by the conference host, control keyboard or computer PC software.
·The system has first in first out work, free discussion, speech mode, queuing mode, computer permission mode and speech time limit mode.
·It has three key or five key voting function, supports key check-in, IC card check-in and supplementary check-in functions, and dynamically displays data.
·The built-in channel selector can be extended to answer in different languages such as 4 / 8 / 12 / 16 / 20 / 32, and supports 64 languages at most.
·The "hot plug" function of live line shall be provided between units.
·With two 3.5 mm headphone sockets.
·Built in 2W high fidelity speaker.
Specification
system capacity | Single channel 20 sets, expandable 65535 sets |
display | 128 × 32 graphic LCD display, 6''glass panel Microphone |
Microphone type | Cardioid directional electret |
Microphone Sensitivity | - 37dB±2dB |
frequency response | 30Hz~20KHz |
Signal to noise ratio | >90dB |
dynamic range | 96dB |
Total harmonic distortion | < 0.05% |
Channel separation | 102dB |
microphone sensitivity | -37dB±2dB |
Connection mode | T-head, ring handle |
Connector | Large 8-core |
Unit opening quantity | 1 / 2 / 3 / 4 / 5 / 6/7/8/9 |
Earphone Output Connector | Φ 3.5mm stereo jack |
Headphone volume | 10mW |
Earphone load | >16Ω |
