PeiParts 703493 130298 Red Nylon Bristle Block 50X50X21mm Cutter Parts for VT2500
PeiParts 703493 and 130298 red nylon bristle block for VT2500 automatic cutting tables. The 50 by 50 by 21 mm block supports the material, maintains vacuum airflow and allows blade penetration during cutting.
The PeiParts 703493 and 130298 Nylon Bristle Block is a replacement consumable for VT2500 automatic cutting machines.
Bristle blocks are installed across the cutting table to create a flexible and air permeable support surface. The dense nylon bristles support the material while allowing vacuum airflow through the cutting bed.
During cutting, the blade can travel slightly into the bristle surface without contacting a solid table base. This helps protect the blade and provides stable support for compressed fabric layers.
Worn, bent or missing bristle blocks may reduce vacuum performance and create an uneven cutting surface. Replacing damaged sections helps maintain material stability and consistent cutting conditions.
| Brand | PeiParts |
|---|---|
| Part Numbers | 703493 and 130298 |
| Product Description | Red Nylon Bristle Block |
| Product Category | Cutter Parts |
| Product Type | Cutting Table Consumable |
| Compatible Model | VT2500 |
| Size | 50 by 50 by 21 mm |
| Material | Nylon |
| Color | Red |
| Reference Weight | Approximately 0.02 kg per piece |
| Application | Automatic Cutter Bristle Bed |
| Condition | New |
| Order Unit | One Piece |
| Packing Quantity | Confirmed According to Order |
| Compatibility Confirmation | Recommended Before Ordering |
- Flexible Material Support
The nylon bristles create a flexible surface that supports fabric and other materials during automatic cutting.
- Vacuum Airflow
The spaces between the bristles allow air to pass through the cutting table and support vacuum hold down performance.
- Blade Friendly Cutting Surface
The cutting blade can enter the bristle surface without contacting a solid base during normal operation.
- Modular Block Design
Individual worn blocks can be removed and replaced without changing the complete cutting table surface.
- Nylon Construction
The flexible nylon bristles recover after repeated blade contact and material compression.
- Standard VT2500 Dimensions
The block measures 50 by 50 by 21 mm for compatible VT2500 cutting table configurations.
- Dual Reference Numbers
Part numbers 703493 and 130298 are commonly associated with this red VT2500 bristle block.
The automatic cutter uses vacuum pressure to hold material layers against the cutting table.
Air is drawn through the gaps between the nylon bristles. This creates suction across the cutting area and helps prevent the material from shifting while the cutting head moves.
The bristles also provide vertical support beneath the material. Their flexible structure allows the blade to penetrate slightly below the material without striking a rigid surface.
When bristles become permanently bent, broken or compressed, the cutting table may develop low areas. These areas can reduce material support and allow unwanted movement during cutting.
Replacing worn cutter parts helps restore a more even bristle bed and consistent vacuum distribution.
Inspect the bristle blocks when you notice any of the following conditions.
- Bristles remain permanently bent
- Bristle height becomes uneven
- The plastic base is cracked or damaged
- Blocks become loose in the cutting table
- Gaps appear between adjacent blocks
- Vacuum holding force becomes uneven
- Material moves during cutting
- Cut pieces show inconsistent edges
- The blade approaches the solid table base
- Fabric dust is trapped beneath damaged blocks
A vacuum problem may also be caused by air leakage, a blocked filter or a damaged covering film. Inspect the complete cutting table system before replacing large quantities.
This listing is for a red nylon bristle block measuring 50 by 50 by 21 mm for VT2500 cutting tables.
Similar red bristle blocks may have different dimensions, base designs, locking structures or bristle heights.
Do not confirm compatibility only according to color.
Please provide the following information before ordering.
- Machine model
- Original part number
- Clear photos of the old bristle block
- Top and bottom photos
- Length, width and height
- Required quantity
- Partial replacement or complete table replacement
- Destination country and postal code
PeiParts will compare the product details before preparing the quotation.
Stop the machine and isolate the power before working on the cutting table.
Identify the damaged areas and record the original block orientation.
Remove the worn bristle blocks carefully without damaging the supporting table structure.
Clean fabric fibers, dust and debris from the mounting area.
Check the base connection and locking position.
Install each new block in the correct orientation.
Confirm that all blocks are seated securely and remain level with the surrounding surface.
Replace adjacent blocks when large differences in bristle height create an uneven cutting area.
Check the vacuum performance after installation.
Complete a trial cut using test material before returning the machine to normal production.
Before shipment, the bristle blocks can be checked for the following items.
- Part number
- Product dimensions
- Nylon bristle condition
- Bristle height
- Bristle density
- Plastic base condition
- Bottom connection structure
- Color consistency
- Order quantity
Product photos and dimensions can be provided for confirmation when required.
PeiParts supplies cutter parts and consumables for automatic cutting machines used in apparel, automotive interior, furniture, leather and industrial fabric production.
Our team helps customers identify bristle blocks using part numbers, machine models, dimensions and product photos.
Customers can request replacement blocks for one damaged section or a quotation for the complete cutting table. Send the cutting area dimensions and existing block layout if you need help estimating the required quantity.
PeiParts supports cutter parts buyers in Indonesia, Brazil, the Philippines, the United States, Egypt and European countries.
The bristle blocks are packed to protect the nylon tufts and plastic bases against compression, moisture and impact during transportation.
Carton quantity will be confirmed according to the order volume and packing requirement.
Shipping can be arranged by international express, air freight or sea freight. Express delivery is suitable for urgent or smaller orders, while air or sea freight may be more economical for larger quantities.
Send your destination country, postal code and required quantity to receive a shipping quotation.
What are cutter bristle blocks used for?
They create the flexible cutting surface of an automatic cutter table. They support the material, allow vacuum airflow and provide space for blade penetration.
What are the product dimensions?
Each bristle block measures 50 by 50 by 21 mm.
What material is the product made from?
The bristles are made from nylon.
Which machine is this block suitable for?
It is intended for VT2500 automatic cutting machines using the corresponding block design.
Are part numbers 703493 and 130298 related?
Both numbers are commonly used to identify this red VT2500 bristle block. Confirm the original block photos and dimensions before ordering.
Can this block be used on VT5000 or VT7000 machines?
No. VT5000 and VT7000 machines normally use a different bristle block structure and different reference numbers. Do not substitute them without confirmation.
Can I identify the correct block only by color?
No. Color is not enough to confirm compatibility. The dimensions, base structure, machine model and part number must also match.
How many bristle blocks do I need?
The quantity depends on whether you are replacing a damaged section or the complete cutting table. Send the cutting area dimensions and existing block layout for quantity estimation.
When should bristle blocks be replaced?
Replace blocks when the bristles are permanently bent, broken, uneven or unable to support the material correctly.
Can PeiParts supply other cutter parts together?
Yes. Send your complete cutter parts list with part numbers and quantities for a combined quotation.
Please send the following information.
- Part Numbers: 703493 and 130298
- Machine Model: VT2500
- Required Quantity
- Partial or Complete Table Replacement
- Destination Country
- Postal Code
- Photos of the Original Bristle Block
- Photos of the Bottom Connection
PeiParts will check compatibility and provide the product price, packing information, availability, delivery time and shipping options.
Contact PeiParts now to source the correct cutter parts and maintain a stable cutting table surface.
Machine manufacturer names and model names are used only to describe product compatibility. PeiParts is an independent supplier of replacement cutter parts.
